Before Using the Range Hood
CAUTION: Before proceeding to the installation, check If items
are missing or damaged, contact the manufacturer.
Observe all governing codes and ordinances. Have a qualified
technician install the range hood. It is the installer’s
responsibility to comply with installation clearances specified
on the model/serial rating plate. The manufacturer declines all
responsibility for improper installation and does not accept
responsibility for appliance warranty in the event of damage
caused by incorrect installation.
YOU WILL BE NEEDING THESE TOOLS FOR INSTALLATION
1.Protective Gloves
2.Spirit Level Ruler
3.Measuring Tape
4.Double Sided Tape or Tape
5.Cross-Head Screwdriver Set
6.Electric drill
Part 8 : Air outlet assembly X 1
Part 12 : Range Hood Body X 1
Part 13 : Lower Chimney X 1
Part 14 : Upper Chimney X 1
Part 10 : Upper Chimney Bracket X 1
Part 11 : Wall Bracket X 1
Part 9 : Lower Chimney Bracket X 1
COMPONENTS:
Part 1 : Wall Plug X 9
Part 2 : Screws (A) X 9
Part 3 : Screws (B) X 6
Part 4 : Aluminum
Exhaust Pipe X 1
Part 5
: Cable Ties
X 2
Part 6
: Installation Manual
X 1
Part 7
: 1:1 Installation Diagram
X 1
6
