Color Force II Plus User Manual V1.1 2 July 2024

www.chroma-q.com

Operation

2.1. Unpacking the units

The Color Force II Plus

package includes the fixture, power cord, mounting bracket, safety

chain and a Quick Start Guide. We recommend that you keep the original packaging in case the

item needs to be returned.

2.2. Cabling

The Color Force II Plus

utilizes Neutrik powerCon true1 connectors for power input and through. The

DMX control data input and through connections from an external control console are via two Neutrik

XLR 5-pin connectors. The chassis are ground bonded.

Note: To avoid overloading the input cable, the maximum length of Color Force II Plus

fixtures for a

single power cable run is 3.6m (12') at 110VAC or 7.2m (24') at 220VAC.

XLR 5-pin Cable: Typical power & data connections

Function

Ground

(Screen)

Data Minus

Data Plus

Spare Data

Minus

Spare Data

Plus

Power Cable:

International

Colour Code

Connections

North

American

Colour Code

Connections

Green and

Yellow

Earth (E)

Green

Ground

(Green)

Blue

Neutral (N)

White

Neutral (Silver)

Brown

Live (L)

Black

Hot (Gold)

Important Notice:

The use of an optically splitters for DMX signal distribution are highly recommended when several

fixture units are not plugged into the same power source.

Maximum Number of fixtures connected in a series:

Important Notice: Actual number of fixtures connected in series may be lower based on your branch

circuit inrush rating.

2.3. Mounting

The Color Force II Plus

fixtures are equipped with built-in mounting brackets or trunnions for floor

mounting. The mounting brackets feature a pair of quick release levers for easy tilt adjustment. Wall

and truss mounting applications may require additional hardware not included.

Note: Secure the fixture with a safety bond. Provisions for fixing holes are built in to the endplates and

fixture brackets.

Fixture

Wattage

@110V

@220V

CF II Plus 72

800W

2 x CF II Plus 72

4 x CF II Plus 72

CF II Plus 48

533W

3 x CF II Plus 48

6 x CF II Plus 48

CF II Plus 12

135W

12 x CF II Plus 12

22 x CF II Plus 12
