Color Force II Plus User Manual V1.1 15 July 2024

www.chroma-q.com

4.10. Fan Speed

The internal fan of the fixture can be set to four speed options to regulate noise levels and the

cooling process.

Note:

Color Force II Plus

TM

unit is internally temperature protected at all times.

To set the Fan Speed Mode,

1.

On the Main Menu, tap Setup

2.

Then tap Fan Speed option

3.

On the Fan Speed screen, select a Fan Speed option, and then tap Apply to

save

4.11. Rotate Display

Display screen menu can be rotated 180° (upside down) by tapping on this button.

To set the orientation of the display,

1. On the Main Menu screen, tap Setup Menu.

2. On the Screen Setup screen, tap RotateDisp

3. The display screen rotates by 180 degrees

4.12. PWM Frequency

The Color Force II Plus ™ has four frequency settings available -750 Hz, 1500 Hz, 3000Hz, 6000 Hz,

12000Hz, 24000Hz. This allows for the LED scan rate to be synchronized with the video camera and

avoid a flickering effect.

Tradeoff: Better dimming is achieved at lower frequencies; flickering effect is minimized at higher

PWM frequencies.

To set the Frequency,

1.

On the Main Menu, tap Setup Menu

2.

On the Setup screen, tap Frequency

3.

On the Frequency screen, select and tap a Frequency option, then tap Apply to save

Quiet

The internal fans are off and light output is reduced by

20%.

Studio

The fan speed is at low velocity and light output is at

100%.

Live

The fan speed is at high velocity and the light output at

100%

Live-

Quiet

Internal fans are turned off when all DMX values are at

0%.
