Installation
12
Electric connection
Before plugging the washer into the mains socket,
make sure that:
The socket is earthed and in compliance with the
applicable law.
The socket is able to sustain the appliance’s
maximum power load indicated on the Technical
Date Plate fixed on the machine.
The supply voltage is included within the values
indicated on the Technical Date Plate fixed on the
washer.
When heating, the maximum current of the
washer is 10A, so please make sure that the
power supply system (voltage, current and the
cable) is applicable to the load of the applied
appliance.
The socket is compatible with the washer’s plug.
If this is not the case, replace the socket or the
plug by a qualified electrician.
WARNING----THIS APPLIANCE MUST BE
EARTHED. THE FOLLOWING OPERATIONS SHOULD
BE CARRIED OUT BY A QUALIFIED ELECTRICIAN.
Replace the supply cable:
If the supply cord is damaged, it must be replaced
with an identical one by the manufacturer, its
service agent or similarly qualified persons in order
to avoid a hazard – risk of electric shock.
Disposing of the plug:
Ensure that before disposing of the plug itself, you
make the pins unusable so that it cannot be
accidentally inserted into a socket.
Disposing of the appliance:
When disposing of the washer please remove the
plug by cutting the mains cable as close as possible
to the plug body and dispose of the plug as
described above.
The appliance is not intended to be operated by
means of an external switching device, Such as a
timer, or separate remote controlled system.
When the appliance is installed, the mains
socket must be within easy reach.
Do not use extension cables, multiple sockets or
adapters.
To remove the plug from the socket, grasp the
plug firmly and pull it out. Do not pull at the cable.
The electrical components must not be
accessible to the user after installation.
Do not connect the machine to electrical outlets
while your hands are wet or damp.
Do not operate this appliance when you are wet
or barefoot.
Do not operate this appliance if it has a damaged
power cable or plug, if it is not working properly, or
if it has been damaged or dropped.
WARNING! The company denies all liability if
and when these norms are not respected.
Technical date
Technical date
Model
WFL85T48W2
Rated washing capacity (kg)
8.5
Rated voltage
220-240V～
Rated frequency
50Hz
Rated power (W)
2000
Washing noise level (dB)
62
Spinning noise level (dB)
76
Spin speed (rpm)
1400
Water pressure (MPa)
0.03 ～ 1.0
Waterproofing grade
IPX4
Water consumption
(litres per wash)
73
Energy consumption
(kWh per year)
321
Net weight (kg)
65
Outer dimension
(WxDxH mm)
600 X 577 X 847
The water consumption of a cold wash cycle is no higher
than a warm cycle.
