Installation
10
Connection the water supplies and
electricity
Connecting the water inlet hose
1. Connect one end of the water inlet hose to a cold
water tap and tighten by hand (see figure). Before
performing the connection, allow the water to run
freely until it is perfectly clear.
2. Connect the other end of the water inlet hose to
the water inlet valve on the rear of the appliance
and tighten by hand.
3. Turn on the tap slowly and make sure there are
no leaks.
Do not twist, squash, modify or cut the hose.
Tighten the end of the hose firmly by hand.
The supply water pressure must be in the
0.03—1.0MPa range. If the water pressure exceeds
this value, please fit a pressure reducing valve.
If the hose is not long enough, contact a
specialized shop or an authorized technician.
Never use second-hand water inlet hose.
Use the new water inlet hose supplied with the
appliance
Connecting the drain hose
Height of drain point
Height difference between the floor and drainage
point: min. 60cm(24 in.) and max. 100cm(39 in.).
Types of drainage hookups
■ Standpipe
Attach the drain hose to the elbow (no supplied,
available from our Customer Service Department).
Position the elbow on the drain hose 4" (100mm)
from end of the hose as shown. Insert this section
of the drain hose into the drain pipe, If the hose is
pushed down too far, this may cause the washer to
self-syphon ie. continuously empty as it is filling.
Secure the elbow and hose with a cable tie to keep
the hose from coming out of the drain pipe during
use.
