MAIN PARTS
1. Folding cot;
2. Cot level pad;
3. Tubes for mounting the second level
(4 pcs.);
4. Carrying and storage bag;
5. Base of the second level;
6. Changing mat for the child;
7. Short tubes with clips for the changing mat
(2 pcs.);
8. Long tubes for the changing mat (2 pcs.);
9. Arch with toys.
1. UNFOLDING THE COT
1-1, 1-2, 1-3 - Remove the cot from the carrying
bag, peel off the velcro strips and remove and
remove the level pad;
1-4 - Unfold the cot as shown in the figure;
1-5 - Fix the short sides (snap/click);
1-6 - Fix the long sides (snap/click);
1-7 and 1-8 - Press down the center of the cot;
1-9 - The cot is unfolded.
IMPORTANT! Make sure the cot is fixed in the
unfolded position!
2. FIRST (LOW) LEVEL OF THE COT
2-1 - Insert the pad (2);
2-2 - Pass the Velcro strips through the holes and
fix them to the bottom of the cot.
3. SECOND LEVEL OF THE COT
3-1 and 3-2 - Fasten the zipper of the second level
(5) around the sides of the cot;
3-3 - Insert the tubes for the second level (3) and
connect them two by two;
3-4 - Insert the pad (2).
4. CHANGING MAT
4-1, 4-2, 4-3 - Thread the long (a) and short (b)
tubes through the corresponding holes of the
damask (c);
4-4 - Press the pin (d) and insert the tubes into
each other until the pin (d) shows through the
hole;
4-5 - Assembled mat;
4-6 and 4-7 - Place the mat on the cot and press
firmly until it locks;
4-8 - Assembled changing mat.
Only place the cot on a at and level surface!
ONLY USE THE WHEELS TO MOVE THE COT!
Do not allow children under 3 years of age to be present before you have fully assembled the product
to avoid access to small and disassembled parts!
Keep plastic packaging away from children to avoid the risk of suocation!
ASSEMBLY AND FUNCTIONS
The cot is designed for newborn babies and toddlers weighing no more than 15 kg.
The changing mat is designed for a child up to 12 months old and weighing up to 11 kg.
The product is delivered by the manufacturer partially assembled. No tools are required to complete
assembly.
WARNING! Follow exactly the instructions and sequence for assembly and use from the text and
illustrations enclosed in the instructions.
WARNING! CHECK THE SECURITY OF THE FIXING AFTER EACH OPERATION
WARNING! The xing of a position is in most cases accompanied by a clicking sound.
WARNING! Keep your hands from pinching when performing individual operations!
9
