Installation Instructions DVM27U Series
8
MEASUREMENT WORKSHEET - DVM27U (2-HIGH)
DW
(MPW /2)
- 2.875 [73.0]
C
L
MPW - 5.75[146.1]
(DW -MPW)/ 2
[(DW -MPW)/2]
+2.875 [73.0]
2.898(2-7/8")
73.6
C
L
2X DH
DH____________IN
DW___________ IN
MPH__________ IN
MPW_________ IN
AFF___________ IN
MPH
DH____________mm
DW___________ mm
MPH__________ mm
MPW_________ mm
AFF___________ mm
AFF
DH - 10.28 [261.1]
FO RMULA TO CENTER
DISPLAYS ON MO UNT
MPW
BOTTOM EDGE
OF DISPLAY
DVLED PANEL: ____________________________
DH = DVLED DISPLAY HEIGHT
DW = DVLED DISPLAY W IDTH
MPH = MOUNTING PATTERN HEIGHT
MPW - MOUNTIN G PATTERN W IDTH
AFF = ABOVE FINISHED FLOOR
C O F MO UNT
TO DISPLAY EDGE
(1X DISPLAY HEIGHT)
L
