Operation
Ovation E-260CW User Manual Rev. 10 -13-
LED Frequency
This option changes the Pulse Width Modulation (PWM) frequency of the LEDs on the
Ovation E-260CW.
1. Go to the LED Frequency main level.
2. Choose an output frequency. (600Hz, 1200Hz, 2000Hz, 4000Hz, 6000Hz, or 25KHz)
Fan Mode
This option toggles the fan speed from being always on and auto control based on the product’s
temperature.
1. Go to the Fan Mode main level.
2. Select a fan mode (Auto, On, Off, or Silent).
Back Light
This setting allows you to set the amount of time the backlight on the Ovation E-260CW’s
display stays on after the last button is pressed on the control panel.
1. Go to the Back Light main level.
2. Select Always On (remains on), 10S (10 seconds), 30S (30 seconds), or 2Min (2 minutes).
Run Time
This option show how many total hours the product has been on.
1. Go to the Information main level.
2. Select Fixture Hours and the amount of hours will show on the screen.
LED Time
This option show how many total hours the LED has been powered on.
1. Go to the Information main level.
2. Select LED Hours and the amount of hours will show on the screen.
Software
Information
This option shows what version of software the Ovation E-260CW is running.
1. Go to the Information main level.
2. Select Version and the version number will show on the screen.
RDM
This option shows the product’s UID #. The UID # is used when using the RDM functionality of
this product.
1. Go to the Information main level.
2. Select UID: and the number will show on the screen.
Configuration
(DMX)
Use DMX configurations to operate the product with a DMX controller.
DMX
Personalities
This setting allows you to choose a particular DMX personality.
1. Go to the DMX Channel main level.
2. Select the desired personality (1Ch, 2Ch, 3Ch, or 6Ch).
• See the DMX Values section for the highest starting address you can select for each
personality.
• Make sure that the starting addresses on the various products do not overlap due to
the new personality setting.
DMX Control
In this mode, each product will respond to a unique starting address from the DMX controller. All
products with the same starting address will respond in unison.
1. Select a DMX personality as shown in DMX Personalities.
2. Set the running mode:
a. Go to the Master/Slave main level.
b. Select the Master programming level.
3. Set the starting address:
a. Go to DMX Address main level.
b. Select the starting address (001–512).
The highest recommended starting address for each DMX mode is as follows:
DMX Personality
DMX Address
DMX Personality
DMX Address
1Ch
512
2Ch
511
3Ch
510
6Ch
507
