Operation
-10- Ovation E-260CW User Manual Rev. 10
4. Operation
Control Panel
Description
Button
Function
<MENU>
Exits from the current menu or function
<ENTER>
Enables the currently displayed menu or sets the currently selected
value into the current function
<UP>
Navigates upward through the menu list or increases the numeric
value when in a function
<DOWN>
Navigates downward through the menu list or decreases the numeric
value when in a function
Control
Options
Set the Ovation E-260CW starting address in the 001–512
DMX range. This enables control of
up to 85 products in the 6-channel 6CH personality.
Programming
Refer to the Menu Map to understand the menu options. The menu map shows the main level
and a variable number of programming levels for each option.
• To go to the desired main level, press <MENU> repeatedly until the option shows on the
display. Press <ENTER> to select. This will take you to the first programming level for that
option.
• To select an option or value within the current programming level, press <UP> or <DOWN>
until the option shows on the display. Press <ENTER> to select. In this case, if there is
another programming level, you will see that first option, or you will see the selected value.
• Press <MENU> repeatedly to exit to the previous main level.
Menu Map
Main Level
Programming Levels
Description
DMX Address <001–512>
Selects DMX address (highest channel
restricted to personality chosen)
DMX Channel
1Ch
1-channel: dimmer
2Ch
2-channel: 16-bit dimmer
3Ch
3-channel: 16-bit dimmer, strobe
6Ch
6-channel: 16-bit dimmer, strobe, auto
programs, auto speed, control
Static
Dimmer
0–255
Controls intensity
Strobe
Controls strobe rate
Auto Show
Auto 1
<1–100>
Selects automatic programs and auto
program speed
Auto 2
Auto 3
Auto 4
Master/Slave
Master
DMX mode (Master)
Slave
Slave mode
Dimmer Curve
SCurve
Sets the dimmer curve
Linear
Square
Inverse Square
Dimmer Mode
Off
No dimmer
Dimmer 1–3
Dimming curves Dimmer 1 (fast) to
Dimmer 3 (slow)
