MX20 LED Display Controller User Manual
www.novastar.tech
3
Max
width/height
Max width: 3840 pixels (3840×600@60Hz)
Max height: 2560 pixels (800×2560@60Hz)
Frame Rates
23.98 / 24 / 25 / 29.97 / 30 / 47.95 / 48 / 50 / 59.94 / 60 / 72 / 75 /
85 / 100 / 119.88 / 120 / 143.86 / 144 Hz
EDID
management
Support standard resolutions, up to 1920×1080@60Hz.
Support custom input resolutions.
HDCP
Support HDCP 1.4.
Interlaced
signal inputs
Not supported
3G-SDI IN
1
Standard
Support ST-424 (3G), ST-292 (HD) and ST-259 (SD) standard
video inputs.
Support 3G-Level A/Level B (DS mode).
Resolution
Max resolution: 1920×1080@60Hz
Frame Rates
23.98 Hz to 60.00 Hz
Interlaced
signal inputs
Support MQ level deinterlacing. The interlaced signals will be
automatically detected and converted to progressive signals.
Outputs
Type
Qty
Description
1–6
6
Gigabit Ethernet output ports. Support hot backup between Ethernet ports.
Max device load capacity: 3.9 million pixels
The maximum load capacity per Ethernet port is as follows. For details, see the
11 Ethernet Port Load Capacity.
− 8bit@60Hz: 659,722 pixels
− 10bit@60Hz: 329,861 pixels. When the controller works with the A10s Pro
receiving card, the capacity can be up to 494,791 pixels.
OPT 1–2
2
10G optical output ports
OPT 1 transmits the data of Ethernet ports 1 to 6.
OPT 2 is the copy channel of OPT 1.
HDMI 1.3 LOOP
2
HDMI loop through. Up to 8 devices can be cabled in one loop.
3G-SDI LOOP
1
SDI loop through. Up to 8 devices can be cabled in one loop.
SPDIF OUT
1
A digital audio output (Reserved)
Controls
Type
Qty
Description
ETHERNET
2
Gigabit Ethernet control ports. Support TCP/IP protocol and star topology.
They have the same functions without priority and order, and can be connected to
VMP software. No switch or router is needed to deploy multiple devices on the
same LAN via device cascading as the network switching function is already built
in. Up to 20 MX20 devices can be cascaded.
