Technical Specifications

Maverick Storm 3 Profile User Manual Rev. 2

6. Technical Specifications

Dimensions and Weight

Note: Dimensions in inches are rounded.

Power

Light Source

Photometrics

Thermal

Control

Ordering

Length Width Height Weight

15.27 in (388 mm) 10.5 in (267 mm) 29.6 in (754 mm) 69 lb (31.3 kg)

Power Supply Type Range Voltage Selection

Switching (internal) 100 to 240 VAC, 50/60 Hz Auto-ranging

Parameter 100 V, 60 Hz 120 V, 60 Hz 208 V, 60 Hz 230 V, 50 Hz 240 V, 50 Hz

Consumption 882 W 878 W 850 W 841 W 844 W

Operating

Current

8.91 A7.28 A4.14 A3.76 A3.64 A

Fuse

F15 AL, 250 V F15 AL, 250V F15 AL, 250V F15 AL, 250V F15 AL, 250V

Power I/O U.S./Worldwide UK/Europe

Power Input Connector Seetronic Powerkon IP65 Seetronic Powerkon IP65

Power Cable plug Edison Bare ended

Type Color Quantity Power Current Lifespan

LED Cool White 1 620 W 4.6 A 50,000 hours

Color Temperature at Full CRI CRI w / Filter

7062 K 72.3 90.2

Beam Angle Field Angle Cutoff Angle Zoom Range

3.4° to 51.6° 3.7° to 55.8° 3.8° to 56.7° 3.4° to 56.7°

Illuminance @ 5 m (Narrow) Illuminance @ 5 m (Wide) Lumens (Source) Lumens (Output)

161,937 lux 1977 lux 54,000 lux 33,077 lm

Maximum External Temperature Cooling System

113 °F (45 °C) Fan-assisted Convection

DMX I/O Connector Art-Net I/O Connector Channel Range

5-pin XLR Seetronic RJ45 34 or 50

Product Name Item Name Item Code UPC Number

Maverick Storm 3 Profile

MAVERICKSTORM3PROFILE

08011925 781462222734

UL 1573

CSA C22.2 No. 166

E113093
