Maintenance

Maverick Storm 3 Profile User Manual Rev. 2

Torque Measurements

To maintain the IP rating when reassembling the product, use the given torque measurements for each of

the following screws and bolts:

Vacuum Test Measurements

Use the IP Tester from Chauvet Professional to ensure the product has been reassembled correctly by

following the information below:

Gobo Maintenance

To ensure optimal operation, 1) inspect and 2) clean gobos every four months. More frequent maintenance

may be necessary if usage is higher.

To inspect, remove each gobo holder and check if:

• The holders are clean (free of dirt, grime, or gunk).

• The gobos are properly installed in the holders.

• All the bearings are in place.

• The holders are rotating freely.

To clean the gobos and the gobo holder, follow the instructions below:

1. Remove the gobos from the holder.

2. Clean the gobos with a soft, lint-free cotton cloth. Use an ammonia-free glass cleaner sprayed to a

piece of lint-free cotton cloth to clean glass gobos.

3. Submerge the gobo holder (without the gobo installed) in a container with a liquid lubricant (i.e.,

WD40) and let it rest for a couple of minutes.

4. Shake the container with the gobo holder inside to help release/loosen any gunk/grime/dirt.

5. Take the gobo holder out of the container and clean it using a small nylon brush.

6. Wipe off all the lubricant from the gobo holder using a piece of lint-free cotton cloth.

7. Apply a small coat of synthetic oil (i.e., Liquid Bearings) to the bearings and rotate it thoroughly in

both directions (needle tip applier recommended). Make sure the gobo holder is rotating freely and

is not making any abnormal noise.

8. Reinstall the gobos in the gobo holder. Make sure the gobos are in the correct positions.

9. Reinstall the gobo holder in the unit.

Fixture Parts Torque Rating (Kgf.cm) Torque Rating (lbf.in)

Screws inside feet 10.1 8.7

Base screws around outside (not the feet) 16.3 14.1

Base screws in middle 35.6 30.8

Omega bracket holder 12.2 10.6

Front and rear base cover 20.3 17.6

Screws around power and data ports 3.5 3

Fuse 6.1 5.2

Center of yoke plate 15.2 13.1

Arm cover screws 25.4 22

Allen Key screws holding in front lens cover 10.1 8.7

Parameters Values

Method Positive

Test pressure 2.18 kPa

Test duration 60 seconds

PASS state leak pressure <0.02 kPa
