Maverick Storm 3 Profile User Manual Rev. 2

DMX Channel Assignments and Values

Control Chart

50 CH / 34 CH

Value Percent/Setting Value Percent/Setting

000  007 No function 096  103 Pan reset

008  015 Blackout during pan/tilt 104  111 Tilt reset

016  023 Blackout while color wheel is moving 112  119 Color wheel reset

024  031 Blackout while gobo wheels are moving 120  127 Gobo wheels reset

032  039 Blackout during pan/tilt/color wheel 128  131 CTB with gobo on

040  047 Blackout during pan/tilt/gobo wheels 132  135 CTB with gobo off

048  055

Blackout during pan/tilt/color wheel/

gobo wheels

136  143 Prism reset

056 No function 144  151 Blades reset

057 600 Hz PWM 152  159 All reset

058 1200 Hz PWM 160  167 Iris reset

059 2000 Hz PWM 168  175 Frost reset

060 4000 Hz PWM 176  183 Zoom reset

061 6000 Hz PWM 184  191 CMY/CTO reset

062 15000 Hz PWM 192  199 Fan mode ECO

063 No function 200  207 Fan mode Full

064 Linear dimmer curve 208  215 Fan mode Auto

065 Square dimmer curve 216  220 Fan mode TV25

066 I square dimmer curve 221  225 Fan mode TV35

067 Scurve dimmer curve 226  230 No function

068 Linear 2 dimmer curve 231  235 Pan/tilt swap on

069  075 No function 236  240 Pan/tilt swap off

076  079 Engage sun shield 241  245 Min Zoom Focus off

080  084 Disengage sun shield 246  250 Min Zoom Focus on

085  095 No function 251  255 No function

34CH 50CH Function Value Percent/Setting

11Pan 000  255 0–100%

2 2 Fine pan 000  255 Fine control (16-bit)

3 3 Tilt 000  255 0–100%

4 4 Fine tilt 000  255 Fine control (16-bit)

55Pan/tilt speed 000  255 Fast to slow

66Dimmer 000  255 0–100%

– 7 Fine dimmer 000  255 Fine control (16-bit)

7 8 Strobe

000  003 Off

004  007 On

008  076 Synchronized strobe, slow to fast

077  145 Pulse strobe, slow to fast

146  215 Random strobe, slow to fast

216  255 On

8 9 Virtual shaking

000  001 No function

002  128 Shaking effect, slow to fast

129  255 Fade effect, slow to fast

910Cyan 000  255 0–100%
