14
Technical Specifications
Cloud 9X IP User Manual Rev. 1
6. Technical Specifications
Dimensions and Weight
Note: Dimensions in inches are rounded.
Power
Operation/Capacity/Consumption
Thermal
DMX
Ordering
Length Width Height Weight
30 in (762 mm) 17.36 in (441 mm) 19.22 in (488.1 mm) 76.6 lb (34.75 kg)
Power Supply Type Range Voltage Selection
Fixed
230 VAC, 50 Hz
Fixed
120 VAC, 60 Hz
Parameter 120 V, 60 Hz 230 V, 50 Hz
Consumption 1213 W 1281 W
Operating Current
10 A 5.59 A
Breaker
10 A, 250 V 10 A, 250 V
Power I/O U.S./Worldwide UK/Europe
Power Input Connector Seetronic Powerkon IP65 Seetronic Powerkon IP65
Power Cable plug Edison Local plug
Fluid Tank Capacity
Primary Water Tank
Capacity
Secondary Water Tank
Capacity
Total Water Tank
Capacity
0.8 gal (3 l) 5.28 gal (20 l) 2.48 gal (9.4 l) 7.77 gal (29.4 l)
Heat-up Time Fluid Consumption
Max Run Time (100%
Output)
Required Accessories
5 minutes 27.8 ml/min (0.007 gal/min) 2 hours LLG
Maximum External Temperature Cooling System
113 °F (45 °C) Fan-assisted Convection
I/O Connector Channel Range
3-or 5-pin XLR 3
Product Name Item Name Item Code UPC Number
Cloud 9X IP Cloud 9X IP 05072617 781462229658
Cloud 9X IP 230V 220VCloud 9X IP 05072677 781462230258
