10
Operation
Cloud 9X IP User Manual Rev. 1
4. Operation
Control Panel Description
Control Options
Set the Cloud 9X IP starting address in the 001-510 DMX range. This enables control of up to 32 products
in the 3-channel personality.
Menu Map
Refer to the Cloud 9X IP product page on www.chauvetprofessional.com for the latest menu map.
Button Function
<MENU> Exits from the current menu or function
<UP/TIMER>
UP navigates upwards through the menu list and increases the numeric value
when in a function.
TIMER starts the timer controlled operation.
<DOWN/VOLUME>
DOWN navigates downwards through the menu list and decreases the numeric
value when in a function.
VOLUME triggers the pump to modify the output volume.
<ENTER/STOP>
ENTER enables the currently displayed menu or sets the currently selected value
into the selected function.
STOP turns the fog output off.
Main Level Programming Levels Description
INTERVAL SET 5-600S Sets the interval fog output time
DURATION SET 5–300S Sets the continuous fog output time
VOLUME OUT 1-100% Sets the fog volume output
FAN SPEED 0-100% Sets the air volume output. Fan stops at 0
HUMIDITY
OFF
Selects the density of the fog output
MINIMUM
MEDIUM
MAXIMUM
DMX 512 1–510 Selects the DMX starting address
RDM-UID _ _ _ _ _ _ _ _ _ _ _ _ Unique RDM identification number
AUTO RUN LAST
SETTINGS
ON
Automatically sets the values to previous
selections
OFF
AUTO-REFILL
ON
Turns on or off the water refill function when
an external hose is connected
OFF
HEATER
ON
Turns on or off the heater function
OFF
WIRELESS PAIRING
ON
Activates the pairing function for wireless
device
OFF
BACKLIGHT TIMER
ON
Turns on or off the timer for the LCD display
backlight
OFF
