PARTS LIST
CHARBROIL.COM
Page 33
NOTE: Some grill parts shown in the assembly steps may differ slightly in appearance from those on your
particular grill model. However, the method of assembly remains the same.
Key Qty Description
1 1 TOP LID
2 1 LID HANDLE
3 2 RUBBER BUMPER, LID STOP
4 2 RUBBER BUMPER, LID FRONT
5 1 TEMPERATURE GAUGE
6 1 LOGO PLATE
7 1 TOP LID HARDWARE
8 5 TUBE BURNER BRACE
9 1 WARMING RACK
10 1 12" PERFORMANCE GRIDDLE
11 2 COOKING GRATE T180
12 1 COOKING GRATE T120
13 1 TUBE BURNER w/ ELECTRODE
14 4 TUBE BURNER
15 5 HEAT TENT
16 1 SIDEBURNER LID
17 1 SIDEBURNER
18 1 SIDEBURNER DRIP PAN
19 1 SIDEBURNER ELECTRODE WIRE
20 1 SIDEBURNER GRATE
21 4 CARRYOVER TUBE
22 1 SIDEBURNER SHELF FASCIA
23 1 CONTROL KNOB, SIDEBURNER
24 1 BEZEL, SIDEBURNER CONTROL KNOB
25 1 SIDEBURNER SHELF
26 1 SIDEBURNER SHELF SUPPORT BRACE
27 1 FIREBOX
28 1 HOSE VALVE REGULATOR ASSY
29 1 CONTROL PANEL
30 5 BEZEL, MAIN BURNER CONTROL KNOB
31 5 CONTROL KNOB, MAIN BURNER
32 1 RIGHT SIDE SHELF
33 1 RIGHT SHELF FASCIA
34 3 TOOL HOOK
35 1 GREASE CUP
Key Qty Description
36 1 ELECTRONIC IGNTION BUTTON
37 1 ELECTRONIC IGNITION MODULE
38 1 RIGHT SIDE SHELF SUPPORT BRACE
39 2 GREASE CUP BRACKET
40 1 TANK HEAT SHIELD
41 1 LEFT CART PANEL
42 1 FRONT DOOR BRACE
43 1 FRONT CART PANEL
44 1 REAR CART PANEL
45 1 REAR BRACE
46 1 STORAGE SHELF
47 1 TANK RETAINING SCREW
48 1 BOTTOM SHELF
49 1 MATCH HOLDER
50 1 MIDDLE PANEL
51 2 RIGHT CART PANEL
52 1 TANK EXCLUSION WIRE
53 1 DOOR
54 2 CASTER, LOCKING
55 2 WHEEL CAP
56 2 WHEEL
57 1 DOOR HANDLE
58 1 MAGNET ASSEMBLY
59 1 DOOR HINGE
60 1 DOOR STOP
61 2 WHEEL AXLE
62 1 DOOR SPRING PIN
Not Pictured
… 1 PRODUCT GUIDE
… 1 HARDWARE PACK
