• ChamSys Remote Control Protocol (serial, or network)
• Open Sound Control (OSC)
• External Tracker send/receive (PSN, OTP, MQ Track)
• Mouse control of pan/tilt
• PB1 to PB10 controlled by DMX input
• Encoder control from MIDI CC / OSC
Unlocked mode is in operation when Mini Connect, Compact Connect, Stadium Connect and
Rack Mount Dongle are connected. GeNetix GN5 and GN10 also fully unlock when connected
via network (subject to number of MagicQ restriction below).
Unlocked mode is also in operation with the following legacy products - PC Wing, PC Wing
Compact, Extra Wing, Extra Wing Compact, Playback Wing, Execute Wing, Stadium Wing,
MIDI/SMPTE.
*Note that the MagicDMX interface (Basic or Full) do not lift these restrictions, as these are
low cost interfaces intended for learning how to program the system.
MagicQ PC/Mac running with the restricted features unlocked, supports control of the first 10
playbacks (PB1 to PB10) via ChamSys remote control protocol, MIDI and automations. This
enables synchronisation with show control systems. Playbacks 11 to 202 can only be
controlled by MagicQ Playback/Execute/Extra Wings. On MagicQ consoles all 202 playbacks
can be controlled by these protocols.
MagicQ PC/Mac supports 400 universes for Previsualisation and 64 universes for full output.
In the MQ250M, MQ500 and MQ500M Previs panel modes in order to protect our customers
investment in full MQ500 and MQ500M consoles, the normal outputs are disabled and only
visualisation is supported. Visualisation can be internal MagicVis or direct network links to
external 3rd part visualisers. When universes 65 to 400 are used with external visualisers
there will be occasional breaks in the DMX to prevent usage to control real lighting rigs.
MagicQ warns if universes are enabled when entering the MQ500 and MQ500M Previs panels.
GeNetix / SnakeSys DMX Node Unlocking
GeNetix GN2 unlocks into Core mode, whilst GeNetix GN5 and GN10 unlock fully.
From v1.9.5.0 onwards GeNetix and SnakeSys nodes connected to MagicQ PC Systems over the
network will only unlock MagicQ systems if there are no more than two MagicQ systems on
the network (PC/Mac or console).
This enables a user to have a master and slave PC for their show unlocked, but prevents
installations where a single GeNetix or SnakeSys device unlocks many MagicQ PC systems.
In previous versions SnakeSys devices would unlock all MagicQ PC Systems connected to the
network.
Product Via USB Via Network
30 ChamSys Manuals 2025-02-12
