SERVICE REPLACEMENT PARTSSERVICE REPLACEMENT PARTS
BOOSTER SUB ASSEMBLY (CONT.)
(section end)
PARTS LIST:
Item
No. Part No. Description Qty.
1 100003 HEX PLAIN NUT, 1/4-20 SST 4
2 100184 NIPPLE, 3/4" NPT X CLOSE, BRASS 4
3 100210 PLUG, 1/8" NPT SQ. HEAD, SST 1
4 100571 UNION, 3/4" NPT, BRASS 1
5 102392 BUSHING, REDUCING, 3/4" NPT X 1/2" NPT, BRASS 1
6 102444 ELBOW, STREET, 3/4" NPT X 90, BRASS 1
7 106026 WASHER, FLAT, 1/4" X 5/8" X .06" SST 1
8 106482 WASHER, LOCK, 1/4" SPLIT, SST 3
9 107550 VALVE, PRESSURE REGULATING, 3/4" NPT, BRONZE 1
10 108528 BARB HOSE EL 1/2" NPT X 1/2" H, BRASS 1
11 108954 HEX GRIP NUT, 6-32 SST W/ NYLON 2
12 109985 O-RING, BOOSTER HEATER 1
13 110562 THERMOSTAT, SNAP, FIXED DISC 1
14 110768 STRAINER, LINE, 3/4" NPT, BRONZE FEMALE 1
15 111233 HEATER, 7.5KW/10KW-208V/240V, 3PH, BOOSTER 1
16 111437 VALVE, SOLENOID 3/4" NPT, HW 1
17 115530 ADAPTER, THERMOMETER, DIGITAL 1
18 333154 BRACKET, PIPING SUPPORT 1
19 0509042 BOOSTER TANK WELDED ASSEMBLY 1
20 0513310 THERMISTOR, PROBE ASSEMBLY UCTR. 1
