33
REPLACEMENT PARTS
DETERGENT TANK
Fig. 12 Part Part Description Qty.
Item No. No.
1 0707415 Detergent Tank (up to S/N 6226)............................................... 1
1 0709054 Detergent Tank (starting @ S/N 6226) ...................................... 1
2 0307296 Detergent Tank Cover Lid.......................................................... 1
3 0307378 Detergent Tank Rear Cover........................................................ 1
4 0707375 Detergent Tank Screen Assembly .............................................. 1
5 0507471 Label, Clean Screens Daily........................................................ 2
6 0700948 Standpipe Assembly................................................................... 1
7 0503670 Float Ball.................................................................................... 1
8 0507426 Float Rod.................................................................................... 1
9 0703673 Cam Bushing c/w Set Screw...................................................... 1
10 0501397 Set Screw, 6-40 x 3/16".............................................................. 1
11 0503701 Timer Shaft Bearing (not req’d after S/N 6226)........................ 2
12 0504864 Label, Data ................................................................................. 1
13 0501896 Thermometer Seal ...................................................................... 1
14 0501600 8" Thermometer ......................................................................... 1
15 0503588 Heater “O” Ring......................................................................... 1
16 0507315 3 KW Heater c/w “O” Ring ....................................................... 1
17 0507323 Thermostat (Capilary only shown) ........................................... 1
18 0501650 Thermostat Adaptor ................................................................... 1
19 0501836 Adaptor “O” Ring ...................................................................... 1
20 0501419 Bolt, 1/4-20 x 1/2" ..................................................................... 1
21 0707383 Drain Pan Screen Assembly....................................................... 1
22 0707380 Drain Pan Assembly................................................................... 1
23 0307423 Heater Cover .............................................................................. 1
24 0503301 Label, Warning ........................................................................... 1
25 0501412 Screw, 10-32 x 3/8".................................................................... 2
26 107435 Nut, M6 ..................................................................................... 4
27 107886 Inlet Chute Gasket...................................................................... 1
28 108051 Elbow Flange ............................................................................. 1
29 0507431 Bolt, M6 x 25mm....................................................................... 4
30 0502563 1" Gear Clamp............................................................................ 1
31 0502668 1" I.D. Braided Hose.................................................................. AR
32 0307427 Inlet Water Tube......................................................................... 1
33 0503679 7/16" Gear Clamp ...................................................................... 2
34 0502665 1/2" I.D. Braided Hose............................................................... 1
35 0502662 1-1/2" Vac-U-Flex Hose............................................................. 23"
36 0502571 1-1/2" Clamp, Hose.................................................................... 1
