REPLACEMENT PARTS
29
CONTROL BOX
Fig. 10 Part Part Description Qty.
Item No. No.
1 0707403 Control Box (prior to S/N 6226)................................................ 1
1 0709049 Control Box (starting @ S/N 6226)........................................... 1
2 0307405 Injector Motor Plate ................................................................... 1
3 0501519 Tie, Nylon 4 in ........................................................................... 6
4 0502666 Hose (1/8" I.D. x 1/4" O.D.) ...................................................... AR
5 0706635 45CC Element Tube................................................................... 2
6 0706634 15CC Element Tube................................................................... 1
7 0707142 Rotor Assembly.......................................................................... 3
8 0506589 Screw, 6-32 x 7/8"...................................................................... 6
9 0504822 Screw, 8-32 x 1/2"...................................................................... 12
10 0501353 Chemical Injector Motor............................................................ 3
11 0507314 Start Capacitor (3 uF)................................................................. 1
12 0307422 Thermostat Bracket .................................................................... 1
13 0501450 Screw, 6-32 x 3/16".................................................................... 4
14 0507323 Thermostat.................................................................................. 1
15 0503592 Label, Ground ............................................................................ 1
15 0501403 Screw, Ground, 10-32 x 3/4" ..................................................... 2
15 0501533 Nut, Ground, 10-32 .................................................................... 2
15 0501493 Washer, Lock, Ground, #10 ....................................................... 2
15 0501472 Washer, Flat, Ground ................................................................. 3
16 0503648 Screw, 8-32 x 5/16".................................................................... 2
17 0503647 Strain Relief Bushing (Medium)................................................ 1
18 0503574 Strain Relief Bushing (Small).................................................... 2
19 0501887 7/8" Button Plug......................................................................... 1
20 0507372 Power Cord................................................................................. 1
21 0503749 Terminal Board........................................................................... 2
22 0701933 Water/Heater Cam c/w Set Screw.............................................. 1
23 0501397 Set Screw, 6-40 x 3/16".............................................................. 1
24 0501379 Float Switch ............................................................................... 1
25 0307369 Nut Plate for Float Switch (starting @ S/N 6226)..................... 1
26 0501433 Screw, 4-40 x 5/8"...................................................................... 2
27 0501411 Screw, 10-32 x 1/4".................................................................... 8
28 0309053 Float Switch Support (starting @ S/N 6226)............................. 1
29 0503642 Label, 2.5 Amp Fuse.................................................................. 1
30 0503693 Label, Switch Up........................................................................ 1
31 0501373 3-Position Switch ....................................................................... 1
32 0501412 Screw, 10-32 x 3/8".................................................................... 8
33 0507470 Label, Injector Prime.................................................................. 1
