REPLACEMENT PARTS
HOOD ASSEMBLY
Fig. 9 Part Part Description Qty.
Item No. No.
1 0703244 Hood, with vacuum breaker at rear............................................ 1
1 0708681 Hood, with vacuum breaker at front .......................................... 1
2 0501497 Lock Washer, #8......................................................................... 4
3 0501408 Screw, 8-32 x 1/4"...................................................................... 12
4 0302997 Curtain Bracket, Outer ............................................................... 2
5 0501743 Curtain........................................................................................ 2
6 0302998 Curtain Bracket, Inner................................................................ 2
7 0501538 Nut, 8-32 .................................................................................... 4
8 0703176 Curtain Assembly Complete ...................................................... 2
9 0507011 Retaining Ring ........................................................................... 2
10 0703702 Disconnect Assembly................................................................. 2
11 0503703 O-Ring for Disconnect ............................................................... 2
12 0703078 Plumbing Cover ......................................................................... 1
