REPLACEMENT PARTS
SPRAY ASSEMBLY
Fig. 6 Part Part Description Qty.
Item No. No.
1 0501746 Manifold Cap ............................................................................. 10
2 0501753 O-Ring........................................................................................ 10
3 0301790 Manifold, Triple ......................................................................... 2
4 0501745 O-Ring........................................................................................ 10
5 0503589 O-Ring........................................................................................ 10
6 0501716 Manifold Retaining Nut ............................................................. 10
7 0307502 Manifold Plug............................................................................. 1
8 0301795 Manifold, Double ....................................................................... 2
9 0303009 Retaining Rod, Triple................................................................. 2
10 0303010 Retaining Rod, Double .............................................................. 2
11 0501718 Spray Tube, Rinse (14 Holes).................................................... 2
12 0501719 Spray Tube, Rinse (13 Holes).................................................... 2
13 0501717 Spray Tube, Wash ..................................................................... 5
14 0501407 Screw, 8-32 x 1/4"..................................................................... 10
15 0501497 Washer, Lock.............................................................................. 10
16 0303091 Retainer, L.H. ............................................................................. 6
17 0303092 Retainer, R.H.............................................................................. 4
