Item Part Description Qty.
No. No.
Control Box Assembly
1 0503647 STRAIN RELIEF BUSHING (LARGE) 1
2 0512713 STRAIN RELIEF BUSHING (1/2") 3
3 0501404 SCREW, 10-32 X 3/8" ROUND HEAD, BRASS 1
4 0501493 WASHER, LOCK #10 EXT. TOOTH BRASS 1
5 0512185 BOLT, HEX FLANGE 1/4-20 X 3/8" SST 2
6 0501533 NUT, 10-32 BRASS 3
7 0501472 WASHER, FLAT, #10 BRASS 2
8 0314412 BOX, CONTROL 1
9 0512663 LABEL, PRIME 1
10 0512539 SWITCH, ROCKER, ON/OFF/FLUSH 1
11 0508710 SPACER, CONTROL BOARD 4
12 0508433 CIRCUIT BOARD, MOTOR CONTROL 1
13 0507323 THERMOSTAT, CONTROL 1
14 0503749 BOARD, TERMINAL 11 PT 2
15 0312590 WINDOW, CONTROL BOX COVER 1
16 0312589 COVER, CONTROL BOX 1
17 0508920 TRANSFORMER, 240VAC/18VAC, 30VA 1
18 0514162 RELAY, DPST 30A, 240VAC, 240VAC COIL 1
19 0312588 PANEL, CHEMICAL PUMP 1
20 0501353 MOTOR, INJECTOR 140 RPM, 24VDC 3
21 0707142 ROTOR, INJECTOR 3
22 0706635 TUBE, ELEMENT 45cc (DET,ERGENT, SANITIZER) 2
23 0706634 TUBE, ELEMENT ASSY 15cc (RINSE-AID) 1
24 0501869 STRAINER 3
25 0306363 TUBE, STIFFENER 3
26 0502666 TUBING, CHEMICAL 1/8" I.D. X 1/4" O.D. A/R
27 0503695 LABEL, DETERGENT 1
---- 0503694 LABEL, SANITIZER 1
---- 0505483 LABEL, RINSE-AID 1
28 0504822 SCREW, 8-32 X 1/2" PAN HD. PHIL. SST 12
29 0501411 SCREW, 10-32 X 1/4" 12
30 0501408 SCREW. 8-32 X 1/4" TRUSS HD. PHIL. SST 2
31 0503648 SCREW, 8-32 X 3/8" PAN HD. SST 2
32 0504823 RIVOT, POP 1/8" ALUMINUM 2
33 0504411 SCREW, 10-32 X 1/4" RD. HD. PHIL. SST 1
34 106695 SCREW, 6-32 X 1/2" ROUND HD. PHIL. 4
35 0501450 SCREW, NIBS RH 6-32 X 3/16" PHIL. SST 2
36 0713778 SNUBBER COMES W/FASTONS 1
---- 0512538-1 HARNESS, WIRING (NOT SHOWN) 1
