Je bekijkt pagina 45 van 50
37
Item Part Description Qty.
No. No.
Detergent Tank Assembly
1 0312592 COVER, STEAM 1
2 0312591 COVER, DETERGENT TANK 1
3 0712641 SCREEN, DETERGENT TANK 1
4 0700948 STANDPIPE, DETERGENT TANK 1
5 201669 LOCKNUT, 1/4 NPT, NICKLE PLATE 1
6 0501397 SCREW, SET 6-40 X 3/16" SOCKET SST 2
7 0703673 COLLAR (SET SCREW INCLUDED) 2
8 0512554 ROD, FLOAT 1
9 0503670 BALL, FLOAT 1
10 0307427 TUBE, WATER INLET 1
11 107967 NUT, GRIP 1/4-20 W/NYLON INSERT 1
12 0502668 HOSE, PVC 1" I.D. X 1-3/8" OD 6"
13 0502563 CLAMP, GEAR 1" 1
14 108051 FLANGE, ELBOW 1
15 0507431 BOLT M6 X 25MM (METRIC) 4
16 107886 GASKET, INLET CHUTE 1
17 107435 NUT, M6 (METRIC) 4
18 0712640 TANK, DETERGENT 1
19 0512185 BOLT, HEX FLANGE 1/4-20 X 3/8" SST 2
20 0512534 TEE, MOLDED DRAIN 1
21 0512536 GASKET, DRAIN 1
22 0512535 DRAIN SEAT, MOLDED 1
23 0501395 SCREW, SET 1/4-20 X 5/16" SST 1
24 0312682 CAM, FLOAT 1
25 0512550 BUSHING, FLOAT ROD 1
26 0502571 CLAMP, HOSE 1-1/2" 2
27 0512533 HOSE, MOLDED DRAIN 1
28 0503723 SCREW, 6/32 X 1" 2
29 0501375 SWITCH, TRIP C/W ROLLER 1
30 0514175 SCREW, NYLOCK 9-32 X 3/8" SST 2
31 0501412 SCREW. 10-32 X 3/8" TRUSS HD. PHIL. SST 1
32 0314416 BRACKET, FLOAT SWITCH 1
33 0502977 WELDNUT, DUAL 6/32 NICKEL PLATED 1
34 0501896 SEAL, THERMOMETER 1
35 0501600 THERMOMETER, 8" STEM 1
36 0507323 THERMOSTAT 1
37 0501650 ADAPTER, THERMOSTAT 1
38 0501836 O-RING 1
39 0503588 O-RING, HEATER (Comes with Item 40) 1
40 0507315 HEATER, DETERGENT TANK 3kW (Includes Item 39) 1
41 0503679 CLAMP, HOSE #6 1
42 0502665 HOSE, BRAIDED 1/2" A/R
43 0507471 LABEL, CLEAN SCREENS DAILY 1
