* 8 ohm compatible.

Cerwin-Vega! is constantly striving to maintain the highest consumer standards. As a result of these efforts, modifications may be made from time to time to existing products without

prior notice. Specifications and appearance may differ from those listed or shown in this manual.

XLS-6C XLS-6 XLS-28 XLS-12 XLS-15 XLS-215

Description Dual 6.5” 2-way 6.5” 2-way Dual 8” 3-way 12” 3-way 15” 3-way Dual 15” 3-way

Frequency

Response

64 Hz - 20 kHz

(-3 dB)

44 Hz - 20 kHz

(-10 dB)

50 Hz - 20 kHz

(-3 dB)

39 Hz - 20 kHz

(-10 dB)

45 Hz - 20 kHz

(-3 dB)

38 Hz - 20 kHz

(-10 dB)

43 Hz - 20 kHz

(-3 dB)

37 Hz - 20 kHz

(-10 dB)

38 Hz - 20 kHz

(-3 dB)

36 Hz - 20 kHz

(-10 dB)

38 Hz - 20 kHz

(-3 dB)

36 Hz - 20 kHz

(-10 dB)

Power Handling

(Peak)

125 watts 125 watts 200 watts 300 watts 400 watts 500 watts

Sensitivity in

SPL @ 8 ohms

@ 1 meter full

89.3 dB 85 dB 89.8 dB 90.8 dB 92.3 dB 95.3 dB

Impedance 6 ohms* 6 ohms* 6 ohms* 6 ohms* 6 ohms* 6 ohms*

Crossover

Frequencies

2 kHz 2 kHz 380 Hz / 2 .4 kHz 380 Hz / 2 .4 kHz 280 Hz / 2 .4 kHz 280 Hz / 2 .4 kHz

Protection Yes (High freq. Only) Yes (High freq. Only) Yes Fuse (system) Yes Fuse (system) Yes Fuse (system) Yes Fuse (system)

Video Shielding Yes Yes No No No No

Dimensions

(HxWxD)

8.1” x 22.9” x 10.3”

205 mm x 580 mm x 260 mm

15.2” x 7.9” x 11.5”

385 mm x 200 mm x 290 mm

33.7” x 11.1” x 12.2”

855 mm x 280 mm x 310 mm

37.6” x 13.8” x 13”

955 mm x 350 mm x 330 mm

40.6” x 17” x 18.5”

1030 mm x 430 mm x 470 mm

49.7” x 17” x 21.1”

1260 mm x 430 mm x 535 mm

Net Weight (lbs) 23 lb / 10.4 kg 16 lb / 7.2 kg 43 lb / 19.5 kg 56 lb / 25.4 kg 85 lb / 38.5 kg 116 lb / 52.6 kg

SPECIFICATIONS
