7
Installation of door handle
(optional)
1. As shown in the figure, align the two
round holes inside the handle base with
the reserved holes on the door, and use
the self-contained Phillips screwdriver to
fasten the two hexagon screws until the
handle base does not shake.
2. Align the handle with the upper and lower
guide slots on the handle base, and push
the handle horizontally from left to right
as shown in the figure until it reaches the
end.
3. Align the countersunk screw with the
reserved hole on the lower side of the
handle and secure it tightly.
ATTENTION
To remove the handle, you need to remove the
screw first, and then slightly shake the handle to
push it out in the opposite direction (from right to
left). Be careful not to push it hard horizontally to
avoid hitting your fingers.
