15
both adjustable bottom feet parts, and
the lower hinge part by unscrewing the
special flange self-tapping screws.
6. Loose out the lower hinge pin,
change it to the reverse hole site, then
tighten it into position follow the picture
below.
7. Replace the lower hinge part to the
left side and fixing it with the special
flange self-tapping screws. Replace the
adjustable bottom feet parts to another
side and fixing it.
8. Transfer the door to the property
position, adjust the lower hinge part,
and make the hinge axis into the lower
hole of the door.
9. Transfer the upper hinge part and
make the upper hinge axis into the
upper hole of the door, and adjust the
position of the door (please support the
door with your hand when doing it),
fixing the upper hinge part with the
special flange self-tapping screws.
10. Install the big screw hole cover
(which is in the plastic bag) on the top
right corner of the refrigerator. Install the
upper hinge cover (which is in the
plastic bag) on the left corner. Put the
other upper hinge cover into the plastic
bag.
