The diagram for xing the kitchen hood to the cabinet is shown in Figure 6.
Fig. 6 key:
1. Drill hole 4 - ø5 mm
2. Drill hole ø130 mm
The installation diagram of the extractor hood to the cabinet is shown in Figure 7.
Fig. 7 key:
1. Furniture
2. Screw 4 - M4x30
3. Gasket (washer) 4 - ø12
4. Air outlet ø120
5. Nut 4 - M4
Air circulation setting (Fig. 8)
Legend Fig. 8:
1. Setting 1
2. Setting 2
3. Setting type adjuster
- Setting 1: turn the adjuster to the outdoor air outlet position. Install the air outlet and
switch on the kitchen hood. The smoke will come out from the outdoor outlet (Fig. 9).
- Setting 2: turn the adjuster to the indoor air outlet position (recirculation system). Install
the air outlet and switch on the kitchen hood. The smoke will come out from the indoor
outlet (Fig. 10).
4. OPERATION
Speed adjustment using the buttons (Fig. 11):
1. Press the power button , the motor will stop.
2. Press the Eco button , the kitchen hood will beep, and the motor will operate at low
speed.
3. Press the II button, the kitchen hood will beep, and the motor will operate at medium
speed.
4. Press the III button, the kitchen hood will beep, and the motor will operate at high speed.
5. Press the light button so that it switches on. Press it again, the light will switch o.
5. CLEANING AND MAINTENANCE
Mesh lter cleaning
- Do not use corrosive detergents to clean grease from the mesh lters. Regular cleaning of
3. INSTALLATION
- Before installing the kitchen hood, make sure that the area is clean to prevent it from
sucking in dust or dirt.
- Please note that the kitchen hood must not share the same ventilation duct with other
appliances that use gas or other fuses.
- To facilitate air outlet, the ventilation duct should have a curvature of ≥120° and should be
connected to the outside wall, parallel to or above the starting point.
- After installation, ensure that the kitchen hood is level to prevent grease build-up on the
end (Fig. 2).
The dimensions of the kitchen hood are shown in Figure 3.
Installation on wall
1. Install the kitchen hood so that there is a minimum distance of 65-75 cm between the
cooking surface and the kitchen hood. Using a drill, drill 4 holes 8 mm and 40 mm deep
into the wall.
2. Insert the plastic plugs into the 4 holes.
3. Attach the air outlet to the ventilation duct at the top of the kitchen hood.
4. Remove the mesh lter, x the kitchen hood to the wall by using the screws. Make sure it
is centred with the worktop and tighten the screws.
5. Replace the mesh lter.
The diagram for xing the kitchen hood to the wall is shown in Figure 4.
Fig. 4 key:
1. Worktop
2. Drill hole 4 - ø8, 40 mm deep
The installation diagram of the kitchen hood to the wall is shown in Figure 5.
Fig. 5 key:
1. Wall
2. Plastic plug 4 - ø8x38
3. Screw 4 - ST 4x30
Installation on kitchen wall unit
1. Using a drill, drill 4 holes of 5 mm and 130 mm at the bottom of the cabinet.
2. Attach the air outlet to the ventilation duct at the top of the kitchen hood.
3. Remove the mesh lter. Insert the plastic plugs into the holes and secure the kitchen
hood to the cabinet using the screws. Make sure it is centred with the worktop.
4. Replace the mesh lter.
