ENERGYSILENCE AERO 5200 BLACK PRO

ENERGYSILENCE AERO 5200 WHITE PRO

44

ENGLISH

3. OPERATION

Installation of the mounting bracket

Fig. 2 key:

A. Concrete ceiling

B. Wooden ceiling

1. Drill a ø 8 mm hole in the ceiling and insert the bolt. Align the bracket with the hole and

tighten it with a nut.

2. Remove the clevis pin and clevis from the downrod. Fig. 3

3. Slide the downrod through the canopy and the coupling cover. Fig. 4

4. Pass the fan wires and the earth wire through the downrod. Fig. 5

5. Loosen the screws of the downrod bracket and then place the downrod in its bracket.

Align the holes in the clevis pin of the downrod with the holes in the bracket. Make sure to

insert the straight part of the clevis pin through the hole in the end of the clevis pin and

press until the crimped part snaps into position. Fig. 6.

6. Finally, retighten the screws.

WARNING: it is very important that the downrod bracket pin is correctly installed and that the

screws are tightened securely. If the pin, clevis, or screws are not correctly positioned, the fan

may fall down.

Installing the blades

7. Remove the motor screws and set them aside to use them in the next step. Fig. 7

8. Place the blades on the bracket and x them using the screws. Place the blade bracket on

the motor assembly. Next, tighten the screws. Fig. 8

Fig. 7 key:

1. Blades xing screws

Fig. 8 key:

1. Blade

2. Blades xing screws

Installing the lamp bracket

9. Remove the screws and set them aside. Fig. 9

10. Fix the lamp bracket on the fan body using the screws. Fig. 10

11. Once the bracket is in place, connect the light input wires. Fig. 11
