ENERGYSILENCE AERO 5200 LIGHT WHITE / BLACK

46

ENGLISH

3. ASSEMBLY

Fig. 2 key:

1. Wood screws

2. Mounting bracket

Fig. 3 key:

1. Expansion bolt

2. Screw hook

3. Drilling diagram

Fig. 5 and 8 key:

L: Live wire

N: Neutral

: Earth wire

Fig. 11 key:

1. Clip

2. Mounting bracket

3. Slot

- Wooden ceiling: secure the mounting bracket rmly to the wooden ceiling beam with a

drill bit. Fig. 2

- Concrete ceiling: you can enlarge the holes in the mounting bracket with an 8 mm ø

medium drill bit. Use the M6 expansion bolts to attach the mounting bracket to the side of

the screw hook. The distance between the screw hooks and the mounting bracket must

be between 8 and 10 mm. The installation of the screw hook must not interfere with the

mounting bracket and must not aect the positioning of the receiver. Fig. 3

1. Loosen the safety rope screw, place the rope ring on the screw hook and tighten the rope.

Finally, retighten the screw. Fig. 4

2. Connect the cables according to the wiring instructions shown in Fig. 5

3. Attach the mounting bracket to the ceiling beam or to a suitable piece of wood inserted

between the ceiling beams. The mounting bracket must be secured with the washers and

screws provided. In case of a concrete ceiling, drill holes with ø 8 mm drill bits, taking into

account the length of the expansion screws used. Then, x the mounting bracket to the

ceiling with the expansion screws. Fig. 6.

4. Fit the blades, insert the screws and tighten them with a nut. Fig. 7

5. Connect the cables as shown in Fig. 8.

6. Remove the clevis pin and clevis from the downrod. Slide the downrod through the

canopy and the downrod cover. Fig. 9
