BOLERO SQUAD G 1200F / 2200F / 3200F / 4200F / 5200F GLASS BLACK
81
ENGLISH
- Observe the minimum clearances to combustible surfaces indicated in this manual. These
must be in accordance with the information on the nameplate and with local regulations
and standards.
- If the hob is installed near a window, appropriate precautions must be taken to prevent
curtains from ying over the burners, as this would pose a serious re hazard.
- When choosing the location of the hob, consider the position of the gas and electricity
supply pipes.
- The gas supply and electrical power must be closed at the time of installation.
- Do not install another hob next to this appliance.
- Check the underside of the worktop to ensure that there are no protrusions. Make sure the
worktop is solid, can support the weight of the hob and is level.
- Make sure that the location where you place the hob is well ventilated. Make sure that the
ventilation is not obstructed by bulky objects, etc.
- Remember to glue the sealing gasket on the hob panel before installing it on the worktop.
- RISK OF CUTS. Please note that the edges of the stainless-steel hobs can cause cuts,
extreme caution must be taken when handling.
- Figure 2 shows the safety distances to be observed when installing the hob.
Installation of the hob under a piece of furniture
- Always make sure the hob is well ventilated and that the air inlet and outlet are not
blocked. Make sure the hob works properly.
- The following table shows the installation dimensions corresponding to gure 3:
A B C D E
700 mm min 100 mm min 20 mm Air inlet Air outlet 5 mm
Note: the safety distance between the hob and a cabinet over the hob must be at least 700 mm.
Warning: in case of breakage of the hob glass (depending on the model):
immediately switch o all burners and any electrical heating elements and
disconnect the appliance from the mains. Do not touch the surface of the
appliance. Stop using the hob.
Installation on a worktop
The following table shows the appliance dimensions and the cutting dimensions of the
worktop, corresponding to gure 4.
