ENGLISH ENGLISH

BOLERO DRESSCODE_8600 INVERTER / 9600 INVERTER / 9600 INVERTER STEEL / 12600 INVERTER

Cleaning the detergent dispenser

Press down the arrow on the softener cover inside the dispenser drawer.

Lift the clip up and take out the softener cover and wash all grooves with water.

Replace the softener cover and push the drawer into position.

Pull out the dispenser drawer by pressing the A. Fig. 29.

Clean the dispenser drawer under running water. Fig. 30.

Clean inside the recess with an old toothbrush. Fig 31.

Insert the dispenser drawer. Fig. 32.

Warning: Do not use alcohol, solvents or chemical products to clean the washing machine.

Cleaning the drain pump filter

Warning:

Be careful with the hot water!

Allow detergent solution to cool down.

Unplug the machine to avoid electrical shock before washing.

The drain pump filter can filter the yarns and small foreign matters from the washing.

Clean the filter periodically to ensure proper operation of the washing machine.

Open the lower cover cap. Fig. 33.

Rotate 90 °C and pull out the emergency drain hose and take off the hose cap. Fig. 34.

When it is fully emptied, reset the drain hose. Fig. 35.

Open the filter by turning it counterclockwise. Fig. 36.

Remove dust, dirt and other substances or objects. Fig. 37.

Close the lower cover cap. Fig. 38.

Warning:

Make sure that the valve cap and emergency drain hose are reinstalled properly, cap plates

should be inserted aligned to the hole plates.

*Some machines don have emergency drain hose, so step 2 and step 3 can be skipped.

Rotate the lower cover cap directly for water to run into the basin.

When the appliance is in use and depending on the programme selected there can be hot

water in the pump. Never remove the pump cover during a wash cycle, always wait until the

appliance has finished the cycle and is empty.

When replacing the cover, ensure it is securely re-tightened.

6. TROUBLESHOOTING

Problem Cause Solution

The washing machine does

not start up

The door is not closed

properly

Restart after the door is

closed.

Check if there are clothes

stuck.

The door does not open The safety lock system is

activated

Unplug it and restart the

product.

Water leakage Bad connection between

pipes and water supply

hose or drainpipe.

Check and fasten water pipes

and hose.

Clean up outlet hose.

Detergent residues in the box Detergent is dampened or

agglomerated

Clean and wipe the detergent

box

Indicator or display does not

light

The power PC board is

disconnected, or harness

has connection problem

Check if the power is shut

down and the power plug is

connected correctly.

Abnormal noise Check if the fixing bolts have

been removed.

Make sure the appliance is

installed on a solid, level

floor.

Errors

Error Cause solution

E30 Door is not closed

properly

Restart after the door is

closed.

Check if there are clothes

stuck.

E10 Water injecting problem

while washing

Check if the water pressure is

too low.

Straighten the water pipe.

Check if the inlet valve filter is

blocked.

E21 Overtime water draining Check if the drainpipe is

blocked.

E12 Water overflow Restart the appliance.
