BOLERO COOLMARKET TT UF 155 WHITE E60

ENGLISH

4. Remove the door from the bottom hinge. Fig. 7

Note

When removing the door, look for washers between the hinge and the bottom of the door that

may stick to the door itself. Do not lose them.

5. Place the door on a smooth surface with the panel facing upwards. Loosen the self-

tapping screws and door stop, then install them on the left side and tighten them

securely. Fig. 8

Legend Fig. 8:

a. Door stop

b. Self-tapping screws

6. Place the freezer on soft foam packaging or similar material. Remove the two adjustable

lower legs and the lower hinge by unscrewing the self-tapping screws. Fig. 9

Legend Fig. 9:

a. Lower hinge assembly (right)

b. Adjustable leg set

c. Self-tapping screws

7. Replace the lower hinge on the left-hand side and secure it with the self-tapping screws.

Replace the adjustable feet on the other side and x them. Fig. 10

8. Shift the door to the desired position, adjust the bottom hinge until its axis ts into the

bottom hole of the door. Fig. 11

9. Move the upper hinge and make the shaft enter the upper hole of the door, then adjust

the position of the door (hold the door with your hands), xing the upper hinge with the

self-tapping screws. Fig. 12

Legend Fig. 12:

a. Upper hinge assembly

10. Install the screw hole cover on the top right corner of the freezer.

Install the top hinge cover (located in the plastic bag, depending on model) in the left corner.

Place the other top hinge cover in the plastic bag. Fig. 13

Legend Fig. 13:

a. Top hinge cover (left)
