COOLMARKET TF 90 WHITE

5756

ENGLISH ENGLISH

During operation, the freezer releases heat into the environment. Therefore, you should leave

at least 30 mm of free space at the top, more than 100 mm on both sides, and more than 50

mm at the rear of the freezer.

W (mm) D (mm) H (mm) A (mm) B (mm) C (°) E (mm) F (mm)

545 566 845 1011 1107 125±5 50 100

Fig. 2

Please note

Figure 2 only illustrates the space required for the freezer.

Stable surface

- Place the freezer on a solid, at surface to keep it stable, otherwise vibrations and noises

will occur.

- Ensure a ventilation free of obstacles around the freezer.

4. OPERATION

1. Clean the interior of the freezer with lukewarm water and detergent. Then, dry it. Wait at

least 4 hours before plugging the freezer back to a power supply.

2. Place the thermostat in position 2 and connect the plug to the power supply. The

compressor will then start operating.

3. Once the internal temperature decreases, you’ll be able to store food inside the freezer.

- If the freezer is installed in a wet place, you must check the earthed cord and the leakage

breaker are working normally. If vibration noises occur due to contact of the freezer with

the wall or if the wall turns black due to air convection around the compressor, remove the

freezer from the wall.

- The installation of the freezer may cause interference in mobile phones, landline phones,

radio receivers, or televisions near the refrigerator, so in this case, keep the freezer as far

away from these objects as possible.

Temperature setting Fig. 3

Use the thermostat to adjust the freezer’s temperature: position 1 corresponds to the hottest-

temperature setting, while position 4 is the coldest-temperature setting. We reccomend

position 2 for normal use.

1. PARTS AND COMPONENTS

Fig. 1

1. Top cover

2. Thermostat

3. Lidded upper tray

4. Middle drawer

5. Bottom drawer

6. Adjustable legs

Warning

- The graphics in this manual are schematic representations and may not exactly match the

product.

- To make the most out of the freezer in terms of energy, place all the shelves and drawers

in their original position, that is, as shown in gure 1.

2. BEFORE USE

- This freezer includes a packaging designed to protect it during transport. Take the freezer

out of its box. You can keep the original box and other packaging elements in a safe place,

this will help you prevent product damage when transporting it in the future. In case

the original packaging is disposed of, make sure all packaging materials are recycled

accordingly.

- Make sure all parts and components are included and in good conditions. If there is any

piece missing or not in good condition, immediately contact the Technical Support Service

of Cecotec.

3. INSTALLATION

Preparing for use

The location you choose for the freezer must be properly ventilated and far from heat sources.

Do not place the freezer near heat sources, like a hob, and avoid direct sunlight to ensure the

cooling eect and save on energy consumption. It is not recommended to place the freezer in a

wet place, as it may rust and cause electrical leakage. The result of dividing the total space of

the room in which the freezer is installed by the amount of refrigerant load in the freezer must

not be less than 8 g/m
