Cecotec Bolero Aguazero 6700 B handleiding

Vaatwasser

Cecotec

119 pagina's

PDF beschikbaar

Handleiding

Bolero Aguazero 6700 B

Bolero Aguazero 6700 Inox B

Bolero Aguazero 6700 Dark B

Bolero Aguazero 6700 B

Bolero Aguazero 6700 Inox B

Bolero Aguazero 6700 Dark B

7978

ENGLISH ENGLISH

- Do not allow wineglasses to come into contact with other objects, as this may cause them

to break.

- Place glasses upside down to facilitate cleaning and drying.

- Place cups, glasses and bowls upside down and make sure they are not stacked.

- Additional items can be placed in the ip tines (some models only).

- Make sure that the tableware does not interfere with the movement of the spray arm.

- When placing larger items in the upper basket, such as wine glasses or tall cups, it may be

necessary to remove the ip tines, if present.

Loading of the ip tines (if your dishwasher model is equipped with it)

Some models are equipped with ip tines on which you can place additional items.

Figure 35 shows a schematic picture of how to load the ip tines.

This can be folded down so that you can place tall cups or wine glasses in the upper basket.

(Fig. 36)

Adjusting the height of the upper basket

By adjusting the height, you can create a large space at the bottom or top of the dishwasher

according to your needs.

Lowering the upper basket

Remove the upper basket from the guide rail and then replace it between the second and third

row of castors. (Fig. 37)

Raising the upper basket

Remove the upper basket from the guide rail and then replace it between the rst and second

row of castors. (Fig. 38)

Warning

Make sure that there is no tableware in the basket before adjusting its height. Otherwise, it

could be damaged, or you could be injured.

Tips:

- Make sure that both sides of the upper basket are at the same height before placing it in

the dishwasher. If the height of the two sides is dierent, the dishwasher door will not be

able to close, and the centre spray arm will not work properly.

- After adjusting the height, check whether the spray arm can rotate freely.

- Check that the spray arm does not collide with objects in the bottom basket.

Loading the cutlery drawer (if your dishwasher model is equipped with one)

This is the most suitable place for cutlery and most of the kitchen utensils used for serving.

The dividers on this tray help to keep cutlery separate, thus improving cleanliness.

Loading the bottom basket

Figure 30 shows a schematic picture of how to load the bottom basket.

To load it eciently, follow the Instructions below:

- Plates should be placed in an upright position. Pots, frying pans and larger plates should

be placed upside down.

- Place soup bowls or similar sized items between the tines.

- Ensure that the handle of large items does not interfere with the movement of the spray

arm.

- Small items such as cups, wine glasses or small plates should not be placed in the bottom

basket, but in the upper basket.

- Make sure that large objects do not interfere with the movement of the spray arm and do

not impede the opening of the detergent dispenser.

- Pots and frying pans should be placed in the bottom basket to keep them cleaner.

Tips:

For best results, the cutlery basket should be placed in the centre of the bottom basket, as

shown in gure 31.

NOTE: cutlery basket not available on all models.

Loading the cutlery basket

Figure 32 shows a schematic picture of how to load the cutlery basket.

The cutlery basket is equipped with a divider to prevent the cutlery from scratching.

The lid on the top of the cutlery basket can be removed. (Fig. 33)

Instructions on how to place the cutlery:

- For optimal cleaning, use the lid of the cutlery basket.

- Place sharp objects (e.g. knives) facing downwards.

- When removing the tableware, start with the cutlery basket to prevent water droplets

from the upper basket from falling on the cutlery.

Warning:

- Take care when inserting and removing sharp items. Place sharp knives with the handle

facing upwards to reduce the risk of injury.

- Prevent sharp objects from scratching the door gasket.

Loading the upper basket

Figure 34 shows a schematic picture of how to load the upper basket.

To load it eciently, follow the Instructions below:

- Place the cups and glasses in the row between the tines of the basket. If you place them

directly on the basket, water spots may appear.
