13

ASSEMBLY AND DISASSEMBLY OF YOUR SB 810 BLENDER

INSERTING THE BLADE REMOVING THE BLADE

Turn the stick attachment upside down.

Place the selected blade on the shaft so

that the cutout in the blade is aligned with

the shaft tip. You will hear aclick sound to

indicate the correct position of the knife.

Then turn the blade clockwise until the tip

on the shaft stops at the edge of the blade

cutout.

Always use the supplied tool to remove

the blade from the shaft. Turn the stick

attachment upside down. Slightly turn the

blade counterclockwise until the shaft tip

is approximately in the middle of the knife

cutout. Insert the blade remover under the

knife blades and use it as alever to release

the knife from the shaft. Carefully remove

the knife from the shaft.

NOTE

Keep the blades out of the reach of

children in the storage box.

During use, the knife walls may deform

slightly. This is normal.

If you need to spread the walls, use asmall

screwdriver with a at end and insert it into

the knife - see the picture below.

If, on the other hand, you need to pull the

walls together, use pliers and carefully pull

the walls together - see the picture below.
