Appendix

SET

SENSOR ZONE

5 mm

Mounting the computer

Attach/detach computer

Test operation

Afterattachingthecomputer,rotatethefrontwheelgentlytocheckthatcurrent

speedisdisplayedonthecomputer.

Ifthespeedisnotdisplayed,refertotheattachmentconditionsinsteps1,2,and4

again.

Adjust the speed sensor and the magnet

The magnet passes through

the speed sensor zone.

The clearance between the

speed sensor and the magnet

is within 5 mm (3/16”).

*Themagnetmaybemountedatanypositiononspokeaslongasattachment

conditionsaresatised.

Holdcomputer.

Pushoutsothatfrontliftsup.

Click

Magnet

Sensor zone

Speedsensor

(3/16”)

Speed

sensor

Magnet
