ELECTRICAL CONNECTION:
The unit must be connected to a single phase mains power supply network at the voltage and frequency indicated on the
characteristics plate of the extractor unit.
The electrical installation must include a bipolar phase switch with a distance between contacts of at least 3 mm.
To make the electrical connection, remove the front cover (A) as explained above, open the connection cover (C) using a
tool as shown in figure, and connect the power cables to the strip (E), the blue cable to N, the brown cable to L and the black
cable to SL, if it is a Timer or Hygro.
Return the connection cover (C) to its original position until it is fixed, and then replace the front cover (A).
The appliance must be permanently connected to a fixed electrical supply installation using twin conductor cable of at least
1 mm
2
in section and a maximum of 1.5 mm
2
.
No earth installation is required as the appliance has double insulation. (Class II). IPX4
Type X-MART TIMER IPX4
Adjust the timer by turning the knob (4) in a clockwise direction to increase the operating time (3’ - 15’).
TypeX-MART HYGRO IPX4
Adjust the operating time by turning the red knob (4) in a clockwise direction.
Adjust the level of humidity by turning the blue knob (5) in a clockwise direction to increase the level.
The series X-MART fitted with a hygrometer incorporate a LED indicator. The LED is lit when the extractor is functioning
either activated by the switch fitted to the appliance itself or another, exterior switch. When the extractor is activated by the
level of humidity the LED is not lit. When the extractor is not operating the LED does not light.
