www.CasablancaFanCo.com
1.888.227.2178
M8549-01 • 08/16/18 • © 2018 Casablanca Fan Company
Wiring: Single Switch
Refer to CAUTION c.1 on pg. 2
Connect the white
(grounded) wire from
the ceiling to the white
wire from the fan.
Connect the three
grounding wires (green,
green/yellow stripe, or
bare copper) coming from
the ceiling, downrod, and
hanging bracket.
Connect the black wire
(ungrounded) from the
ceiling to the black wire
from the fan.
Cap the blue wire from
the fan. You will not
need it for single switch
wiring.
Note: To connect the wires,
hold the bare metal leads
together and place a wire
connector over them, then
twist clockwise until tight.
Turn the splices upward and push them carefully back through the hanger bracket
into the outlet box. Spread the wires apart, with the grounded wires on one side of
the outlet box and the ungrounded wires on the other side of the outlet box.
Have a single switch?
Follow these steps:
Dual Switch
Instructions
Black
Blue
Green/Yellow Stripe
White
Ungrounded
Grounded
Grounding
G
r
e
e
n
/
Y
e
l
l
o
w
S
t
r
i
p
e
10
