24

5. dIsassemblIng and storage

! Before disassembling ensure that the load has been removed.

The Pedestal can be disassembled for transport and storage. Proceed as follows:

• Lock the casters posion along the skid leg with levers (24).

• Lock the three wheels with the wheel locks (25).

! ATTENTION: beware of the column rebound when the load is removed.

• Remove the load (camera, lens, monitor, etc.).

• Depressurize the Pedestal to 1,5/2,0 bar (total bleeding is not compulsory).

• Open the safety latch (19) and push down the column (2) to engage the safety latch (19) to the

safety hooking bar (3).

• Loosen the tripod leg levers (5) and the skid clamp (20).

• Li the one stage column and the steering wheel assembly, extend the tripod legs (14) in the

upper posion and lock the tripod leg levers (5).

• The connecon element (7) must stay connected to the column (4).

• Unlock the three rubber hooks (22), detach foot of one of the three tripod legs (21) inserted in

seat (23).

• Lean the column assembly sideways - see red arrow - and detach the other two tripod legs.

11
