19

12

1

3.2 mountIng the Camera

Lock the wheels by pushing down the lock lever (25) on each wheel.

Lower the column pushing it down and lock the safety latch (19) to the safety hooking bar (3).

Fix the pan and lt Head directly on the top of the Pedestal or – if needed - using one of the accessories

(see 2.2 Compable equipment – Oponal accessories) and secure the 4 retaining bolts (E) underneath

the steering wheel with the Allen key (F) on the mounng plate (18).

Place the Camera on the pan and lt Head and add all required addional equipment (lens, prompter,

viewnder, pan bars, etc).

Release the safety latch (19).

3.3 PressurIzIng the Pedestal and balanCIng the load

The compressed air provided to the product must be dry, without oil and dust.

The pneumac power should be provided through the intake valve (29) using the manual pump (C)

which is included with the product or by means of an air-compressor. Remove valve cap and inate the

Pedestal.

The column should be lled with clean pressurized air or nitrogen unl it compensates the weight of the

Camera conguraon.

To pressurize the Pedestal connect either the manual air pump provided with the system or the air-com-

pressor to the intake valve (29), by screwing in the pump connecon.

Inate the system unl the column rises and reaches and maintains the top upper posion. Remove the

air intake connecon.

Bleed the air excess, pushing the pin in the intake valve (29) with the reversed cap unl the Camera

moves freely up and down through the enre range of the column stroke. The Camera is now balanced.

Recap the valve (29).

! Before pressurizing the Pedestal it is necessary to unlock the column by releasing the

safety latch (19).
