Install the column in the skid as follows:
Keep the column in vercal posion and open outwards the three tripod legs (14).
Loosen the tripod leg lever (5), extend each tripod leg (14) to its maximum length and lock with tripod
leg lever (5).
Place the three tripod legs feet (21) on the foot inserng seats (23) on the skid arms, checking that the
tripod legs feet (21) are perfectly coupled on the foot inserng seats (23) and push them down unl
feeling a click.
Secure with rubber hooks (22).
Loosen skid clamp (20) and the column lock (6), move the connecon element (7) to the lowest posion,
inserng it with cauon in the central hole of the Skid (9).
The skid arms locking lever (17) and the column lock (6) must be aligned.
Lock skid clamp (20) and the column lock (6).
4
17
5
14
9
7
20
23
21
6
22
