ComfortVu™ BACnet Thermostat Model Standard TB-HM (Line voltage)Carrier Proprietary and Confidential CARRIER CORPORATION ©2024
Installation and Operation Guide All rights reserved
2
Sensing element:
Temperature
Humidity
Range
41° F to 95° F (5° C to 35° C)
10% to 90 %
Accuracy
±1.0° F (0.5° C)
±3.0% typical
Motion Sensing:
Sensor Type
Distance
Detection range
Movement speed
Detection object
PIR, quad, omnidirectional
16.4 feet (5m)
(HxV) 90° x 30°
2.62 to 3.94 ft/s (0.8 to 1.2 m/s)
15.75 x 9.84 in. (400 x 250 mm)
Power 85-240 Vac line voltage: 1.5 VA unit, 920 VA full load
NOTE
Devices connected to outputs, such as a fan, will increase VA
requirements.
Communication BACnet MS/TP with baud rates up to 76.8 kbps (default baud rate is 38.4
kbps), detected and set automatically by the BACnet Thermostat. Max 127
devices.
Inputs T1, 0 – Normally open or normally closed dry contract, or
0-10 Vdc analog input, or
50 kOhm thermistor @ 25°C
A, B - Communication +/- (RS485)
IN1, 0 - Normally open or Normally closed dry contract, or
0-10 Vdc analog input, or
50 kOhm thermistor @ 25°C
C, R - Power: 24 Vac
Outputs 11, 12, 13 – Digital outputs, 3A max.
14 – Digital outputs 0.3A max.
15 and 16 – Depends on application.
Digital output 0.3A max., or
Analog output 0-10 Vdc, 5 mA max., not isolated
Environmental operating range 50° to 122° F (10° to 50° C), 10 to 90% relative humidity, non-condensing
Mounting
unt on a standard 4" x 2" electrical box using provided 6/32 x 1/2” mounting
Weight 4.8 oz (0.14 kg)
Specifications
