Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations.
Catalog No. 04-53390031-01 Printed in U.S.A. Form 39S-4SI Pg CL-1 9-22 Replaces: 39S-3SI
START-UP CHECKLIST — 39SH,SV,SM,SR UNITS
I. PRELIMINARY INFORMATION
MODEL NO.JOB NAME_________________________
SERIAL NO. ADDRESS ________________________
START-UP DATE______________________________
TECHNICIAN NAME
__________________________
ADDITIONAL ACCESSORIES
_____________________________________________________________________________________________________
II. PRE-START-UP
CONTROLS
Are thermostat(s) and indoor fan control wiring conne
ctions made and checked? (Y/N) _____
Are all wiring terminals tight? (including power to fan motors, heaters, etc.) (Y/N) _____
ELECTRICAL
Does electrical service correspond to unit nameplate? (Y/N) _____
Nameplate Supply Voltage/Phase: Rated __________ Measured __________
Nameplate Rated FLA Motor Current: Rated __________ Measured __________
Does setting for overload device (factory or field-provided)
match motor FLA? (Y/N) _____
Does all field wiring conform to unit wiring diagram? (Y/N) _____
AIR HANDLER
Remove packaging and any construction debris. (Y/N) _____
Inspect for shipping and/or handling damage, make claims as required. (Y/N) _____
Inspect all panel flanges for damage. Panel flanges should be smooth with no sharp bends. (Y/N) _____
Are all corner connectors and frame to channel joints smooth
with no cracks, large bumps,
or depressions in the caulk? (Y/N) _____
Are any door latches loose or damaged? If so, tighten or replace. (Y/N) _____
Remove red shipping screws from blower discharge (fan stabilizers during shipping). (Y/N) _____
Check fan bearings and shaft(s) for tightness. (Y/N) _____
Hand turn fan to ensure no rubbing with housing. (Y/N) _____
Have fan and motor pulleys been checked for
proper alignment? (Y/N) _____
Do the fan belts have proper tension? (Y/N) _____
Check fan speed with a laser-type tachometer or use VFD output to confirm operating speed. (Y/N) _____
Are proper air filters in place? (Y/N) _____
Are all wiring terminals to fan motors and heaters tight? (Y/N) _____
Is duct connected to unit? (Y/N) _____
Is unit properly supported? (Y/N) _____
Is unit level (for effective co
ndensate drainage? (Y/N) _____
Verify wiring is correct for application (voltage, etc.) per component label. (Y/N) _____
Are field wiring penetrations into 39S properly sealed for air and water leaks (includes conduit inside box)? (Y/N) _____
NOTE: To avoid injury to personnel and damage to equipment or
property when completing the procedures listed in this start-up
checklist, use good judgment, follow safe practices, and adhere to
the safety considerations/information as outlined in preceding sec-
tions of this Installation Instruction document.
