Info@CarnivalKingSupplies.com | CarnivalKingSupplies.com
Frozen Beverage Dispenser
User Manual
NO. CODE DESCRIPTION
1 3016 Lid
4 3014 Curved Profile
6 3015 Bowl
7 2150 Rotation Pin
8 2117 Tap Lever
9 2149 Fixing Knob
10 2120 Tap Spring
11 3004 Tap Valve
12 3003 Spiral Blade
13 2115 Spiral Blade Gasket
14 2137 Slush/Drink Switch
15 56 Spiral Blade Switch
16 2160 Thermostat
17 0666 Complete Drip Tray
18 182 Fan Motor 220-240V • 50/60Hz
18 68 Fan Motor 115V • 60Hz
19 0159 Rubber Leg H=35
20 * Compressor 220-240V • 50/60Hz
20 * Compressor 115V • 60Hz
21 * Electrovalve
23 2157 Thickness Control Spring
25 57 Main Switch
26 2108 Back Support Cover
27 2131 Motor-Gearbox Support
28 * Motor-Gearbox 220/115V • 50/60Hz
29 2168 Micro-Switch
30 2116 Bowl Gasket
31 3005 Evaporator
NO. CODE DESCRIPTION
32 2145 Evaporator Cover
33 3007,01 Transmission Sha
34 2111 Metal Ring M25
35 2123 Evaporator Cover Inner OR (Small)
36 154 Evaporator Cover Inner OR (Large)
37 2159 Complete Lid
38 * Cable Cord
40 2169 Thickness Control Knob
41 3017 Evaporator Plate
43 3008 Side Panel
45 3021 Front Panel
46 3024 Back Panel
47 2175,01 Condenser
48 * Electric Parts Kit
49 2118 Lubricant Tube
51 2105 Coil 220V • 50/60Hz
51 2183 Coil 115V • 50/60Hz
54 3004,01 Tap Valve OR (Small)
55 3004,02 Tap Valve OR (Large)
Parts Diagram - SMM1
* Mention Compressor Model & Voltage
