Positioning your pads
Once your drum set is assembled, you can further adjust the positioning of the frame and pads to
suit you. The drum set should be comfortable and all pads should be easy to reach without over
stretching.
1. The horizontal frame bars and snare arm can be adjusted up and down to suit drummers of
different heights. Loosen the outside bolt on both ends, and slowly move the bar to your desired
height, tighten the bolts to secure the position.
2. The frame width can be adjusted by turning the outer legs inwards or outwards allowing the Hi-
Hat cymbal, sound module and Tom3 to be positioned closer or further away as needed.
3. The Mesh pads can be moved up/down, left/right, forwards/backwards and also be tilted
upwards and downwards. It is ideal to position the Tom pads in such a way to reduce the risk of
accidentally striking the pad rim.
4. The cymbals can move up/down and also be tilted, it is important that the cymbals are hit on
the rubber playing surface and not the plastic part to reduce noise and possible damage.
5. The Sound module and Hi-Hat cymbal can reverse positions to allow for a wider or narrower
playing area. Place the Hi-Hat in the inner holder for a closer set up, or in the outer holder for a
larger set up.
Frame width
adjustment
Cymbal
height
Adjustment
Cymbal tilt
adjustment
Mesh pad
Adjustments
Frame height
adjustment
Sound Module
Hi-Hat Cymbal
positions
6
