95
ENG
iJW +0300103EN rel. 1.1 - 31.03.2025
Index
431 - Compressor - Defrost - Fan - Humidifi er
NO1
NO4
NO2
NO3
431
S2
DI2
SmSd
Sd
S1
Sm
S5
SHu
SHu
BMS
Sm Sd
S1 S2
GND
NO1
C1
NO2
NO3
NO4
L
N
Tx/Rx
GND
+
DI1 DI2
GND
L
N
5V
S5
SHu
Fig. 12.ag
Parameters list of confi gurations with 4 relays
When choosing a confi guration, the parameters shown in the table are automatically set.
Par. Description Confi guration
403 404 405 406 407 408 409 411 416 417 418 419 420 421 422 423 424 425 426 430 431
/FA Assign outlet temperature probe Sm 1 1 1 111111111111111111
/Fb Assign defrost temperature probe Sd 0 2 0 000002000220000022
/Fc Assign intake temperature probe Sr 0 0 0 000000000000000030
/FP Assign humidity probe 000000050000000055505
DOA Assign solenoid/compressor digital output 111110011111111111111
DOb Assign alarm digital output 004000400400044400000
DOE Assign light digital output 000400000040403000040
DOG Assign defrost digital output 020200002000220000222
DOI Assign evaporator fan digital output 300003003333332333233
DOu Assign humidifi cation digital output 0 00000040000000044304
DOv Assign reverse digital output with dead band
control
000022200002000202000
GF2 Custom function associated with the DOWN
arrow
000100000010101000010
/P2 Confi guration of multifunction input S3/ DI 5 55555555555555555535
Tab. 12.c
