86
ENG
iJW +0300103EN rel. 1.1 - 31.03.2025
Index
12.3.1 Procedure for setting the default parameters/loading the parameter sets
Par. Description Def. Min. Max. UOM User User term.
IS Working confi guration 0 0 IS_Max - S YES
IS_max Number of embedded confi gurations 0 0 999 - S NO
rSC Restore default values 0 0 1 - S YES
User terminal (see “User interface” for details)
Procedure:
1. enter the parameter setting menu;
2. use the UP and DOWN buttons to scroll the submenus until selecting “Ctl”;
3. use the UP and DOWN buttons to scroll the parameters until selecting “rSC” to restore the Carel default values, or “IS” to load
one of the parameter sets available on the controller;
4. to reset the parameters to the default values, after having selected parameter “rSC”, press UP/DOWN to set the value 1 and
confi rm by pressing PROGRAM;
5. to load one of the parameter sets available on the controller, after selecting parameter “IS”, press UP/DOWN to choose the
value corresponding to the parameter set to be loaded as the working set, and confi rm by pressing PROGRAM.
Applica
Procedure:
1. open Applica on the smartphone;
2. access the controller via NFC or Bluetooth™, entering your profi le credentials;
3. scroll to parameter “rSC” (if enabled in the access profi le) to restore the Carel default values, or “IS” to load one of the param-
eter sets available on the controller;
4. set parameter “rSC” or “IS” and confi rm.
Notice: the visibility of parameters “rSC” and “IS” depends on the access profi le used and whether or not there are any em-
bedded confi gurations, respectively.
Applying a confi guration means copying the set values of the confi guration parameters to the working parameters. Any emp-
ty parameters (parameters without values set in that confi guration) will remain unaff ected. The copy procedure is started by
changing the value of parameter IS.
Once the confi guration has been applied, the value of any of the parameters can be modifi ed without aff ecting the confi gura-
tion loaded on the controller, which can thus be recalled at any time, fi rstly setting the corresponding parameter to 0 and then
to the value associated with the desired confi guration.
Notice:
• the parameters contained in a confi guration cannot be modifi ed in any way.
• Any parameters that are not included in the confi guration will remain unchanged, even if the confi guration used is changed.
• Recalling the factory parameters resets the settings without however changing the confi gurations.
12.4 Copy con guration parameters
To simplify operations in the fi eld, Applica includes a “Clone” feature to acquire the confi guration from one iJW and replicate it
on other controllers.
Procedure:
1. open Applica on the smartphone;
2. access the controller via NFC or Bluetooth™, entering the profi le credentials;
3. follow the path "Confi gurations/Clone";
4. move the smartphone closer to the iJW controller to acquire the confi guration from (NFC connection only);
5. following the acknowledgement message, move the smartphone closer to the iJW controller to apply the same confi gura-
tion to (NFC connection only);
6. wait for the cloning confi rmation message to be shown.
Notice: cloning copies all of the parameters, even those not visible to the user based on the access profi le. On the other
hand, to copy only the parameters that are visible to the user, use the “Create confi guration” option, accessible from Service Area
-> Setup -> Parameter list.
