85
ENG
iJW +0300103EN rel. 1.1 - 31.03.2025
Index
Analogue inputs
Code Description Def Min Max UOM User User term.
/P1 Confi guration of probes S1, S2, S3, S4, B5
0 = PT1000; 1 = PTC; 2 = NTC; 3 = NTC-LT; 4 = NTC-HT
2 0 4 - S NO
/P2 Confi guration of multifunction input S3/ DI1: 0, 1, 2, 3, 4 = S3; 5 = DI1 5 0 5 - S NO
/FA Assign outlet temperature probe (Sm)
0 = Function disabled 4 = Probe S4
1 = Probe S1 5 = Reserved
2 = Probe S2 6 = Not available
3 = Probe S3 7 = Not available
1 0 7 - S NO
/Fb Assign defrost temperature probe (Sd) - see /FA 0 0 7 - S NO
/Fc Assign intake temperature probe (Sr) - see /FA 0 0 7 - S NO
/FF Assign auxiliary evaporator defrost temperature probe (Sd2) - see /FA ... 0 7 - S NO
/FG Assign auxiliary temperature probe 1 (Saux1) - see /FA ... 0 7 - S NO
/FH Assign auxiliary temperature probe 2 (Saux1) - see /FA ... 0 7 - S NO
/FI Assign ambient temperature probe (SA) - see /FA ... 0 7 - S NO
/FM Assign glass temperature probe (Svt) - see /FA ... 0 7 - S NO
/Fo Assign condensing temperature probe - see /FA ... 0 7 - S NO
/FP Assign humidity probe (fi xed on S5) ... 5 5 - S NO
/Fq Assign frost protection temperature probe - see /FA ... 0 7 - S NO
/FR Assign product temperature probe - see /FA ... 0 7 - S NO
To set the type of probe, use parameter /P1.
Digital inputs
Code Description Def Min Max UOM User User term.
DIA
Assign immediate external alarm digital input:
0 = Disabled; 1 = DI1; 2 = DI2; 3, 4 = Not available
...
04-
S
NO
DIb Assign delayed external alarm digital input - see DIA
...
04-
S
NO
DIc Assign enable defrost digital input - see DIA
...
04-
S
NO
DId Assign start defrost digital input - see DIA
...
04-
S
NO
DIE Assign door switch with compressor OFF
compressore - Vedere DIA
...
S
DIF Assign remote ON/OFF digital input - see DIA
...
S
DIG Assign curtain switch digital input - see DIA
...
04-
S
NO
DIH Assign start/stop continuous cycle digital input - see DIA
...
04-
S
NO
DIP Assign door switch without compressor OFF
compressore - Vedere DIA
...
04-
S
NO
DIS Assign generic function alarm digital input logic - see DIA
...
04-
S
NO
DIt Assign low pressure switch digital input - see DIA
...
04-
S
NO
DIU Assign AUX output activation digital input - see DIA
...
04-
S
NO
Digital outputs
Code Description Def Min Max UOM User User term.
DOA Assign solenoid/compressor digital output
0 = not confi gured 4 = digital output 4 (NO4)
1 = digital output 1 (NO1) 5 = digital output 5 (NO5)
2 = digital output 2 (NO2) 6 = digital output 6 (NO6)
3 = digital output 3 (NO3)
(***) 0 6 - S NO
DOb Assign alarm digital output - see DOA (***) 0 6 - S NO
DOC Assign AUX auxiliary digital output - see DOA (***) 0 6 - S NO
DOE Assign light digital output - see DOA (***) 0 6 - S NO
DOG Assign defrost digital output - see DOA (***) 0 6 - S NO
DOH Assign auxiliary evaporator defrost digital output - see DOA (***) 0 6 - S NO
DOI Assign evaporator fan digital output - see DOA (***) 0 6 - S NO
DOj Assign dehumidifi cation heater digital output - see DOA (***) 0 6 - S NO
DOk Assign auxiliary compressor without rotation digital output - see DOA (***) 0 6 - S NO
DOn Assign pump down valve digital output - see DOA (***) 0 6 - S NO
DOP Assign drain heater digital output - see DOA (***) 0 6 - S NO
DOQ Assign anti-sweat heater digital output - see DOA (***) 0 6 - S NO
DOS Assign generic On/Off function digital output - see DOA (***) 0 6 - S NO
DOt Assign condenser fan digital output - see DOA (***) 0 6 - S NO
DOu Assign humidifi cation digital output - see DOA (***) 0 6 - S NO
DOv Assign reverse digital output with dead band control - see DOA (***) 0 6 - S NO
DOw Assign auxiliary parallel compressor digital output - see DOA (***) 0 6 - S NO
DOx Assign gasket heater digital output - see DOA (***) 0 6 - S NO
DOy Assign auxiliary compressor with rotation digital output - see DOA (***) 0 6 - S NO
DOz Assign external dehumidifi er digital output - see DOA (***) 0 6 - S NO
12.3 Setting the default parameters/loading the parameter sets
The working set contains the group of parameters used by the iJW controller during normal operation. This set is loaded when-
ever the iJW controller is started, and the parameters can be modifi ed at any time from the terminal, supervisor, Applica app
and Applica Desktop confi guration software. This set of parameters, customised by the user to control their refrigeration system,
can be saved in a confi guration using Applica. Subsequently the confi guration can be retrieved and loaded onto the controller
again using Applica. iJW also stores a default parameter set in its memory; this set can never be overwritten, being stored in a
non-modifi able memory area. The default confi guration can be loaded to restore the system to factory conditions.
In addition, various parameter confi gurations are pre-loaded on the iJW in the internal memory of the device, which can be
copied to the working set if desired, see the paragraph ''List of available confi gurations and relative connections''. A specifi c
parameter can therefore be set to apply the diff erent confi gurations directly from the terminal or in Applica.
