83
ENG
iJW +0300103EN rel. 1.1 - 31.03.2025
Index
12. APPENDIX
12.1 ir33 and IJ parameter compatibility table
The table below shows the parameters from the Carel PJ and IR33 platforms that have changed name or function in the IJ plat-
form. The parameters not listed in this chapter have retained the same name and the same function.
ir33 iJ Description Default Min Max UOM
AF - Not present - - - -
AP - Not present - - - -
Apd - Not present - - - -
H6 - Not present - - - -
H9 - Not present - - - -
/c1, /c2,
/c3, /c4, /c5
/cA Outlet temperature probe (Sm) calibration 0 -20/ -36 20/ 36 Δ °C/ °F
/cb Defrost temperature probe (Sd) calibration 0 -20/ -36 20/ 36 Δ °C/ °F
/cc Intake temperature probe (Sr) calibration 0 -20/ -36 20/ 36 Δ °C/ °F
/cF Auxiliary evaporator defrost temperature probe (Sd2) calibration 0 -20/ -36 20/ 36 Δ °C/ °F
/cg Auxiliary temperature probe 1 calibration 0 -20/ -36 20/ 36 Δ °C/ °F
/cH Auxiliary temperature probe 2 calibration 0 -20/ -36 20/ 36 Δ °C/ °F
/cI Room temperature probe calibration 0 -20/ -36 20/ 36 Δ °C/ °F
/cM Glass temperature probe calibration 0 -20/ -36 20/ 36 Δ °C/ °F
/co Condensing temperature probe calibration 0 -20/ -36 20/ 36 Δ °C/ °F
/cp Humidity probe calibration 0 -20/ -36 20/ 36 Δ °C/ °F
/cq Frost protection temperature probe calibration 0 -20/ -36 20/ 36 Δ °C/ °F
/cr Product temperature probe calibration 0 -20/ -36 20/ 36 Δ °C/ °F
/A2, /A3,
/A4, /A5
/FA Assign outlet temperature probe (Sm)
0 = Function disabled
1 = Probe S1
2 = Probe S2
3 = Probe S3
4 = Probe S4
5 = Reserved
6 = Not available
7 = Not available
... 0 7 -
/Fb Assign defrost temperature probe (Sd) - see /FA ... 0 7 -
/Fc Assign intake temperature probe (Sr) - see /FA ... 0 7 -
/FF Assign auxiliary evaporator defrost temperature probe (Sd2) - see /FA ... 0 7 -
/FG Assign auxiliary temperature probe 1 (Saux1) - see /FA ... 0 7 -
/FH Assign auxiliary temperature probe 2 (Saux1) - see /FA ... 0 7 -
/FI Assign ambient temperature probe (SA) - see /FA ... 0 7 -
/FM Assign glass temperature probe (Svt) - see /FA ... 0 7 -
/Fo Assign condensing temperature probe - see /FA ... 0 7 -
/FP Assign humidity probe (fi xed on S5) ... 5 5 -
/Fq Assign frost protection temperature probe - see /FA ... 0 7 -
/FR Assign product temperature probe - see /FA ... 0 7 -
H2 /nE Enable user terminal navigation:
0= enabled;
1 = disabled
2 = Remote ON/OFF
3 = On/Off and access to set point disabled.
003-
/P /P1 Confi guration of probes S1, S2, S3, S4, B5
0 = PT1000; 1 = PTC; 2 = NTC; 3 = NTC-LT; 4 = NTC-HT.
2 0 4 -
/P2 Confi guration of multifunction input S3/DI1:
0, 1, 2, 3, 4 = S3; 5 = DI1.
5 0 5 -
/tI /t1 Display on user terminal:
0 = Not confi gured
1 = value of S1
2 = value of S2
3 = value of S3
4 = value of S4
5 = value of S5
6 to 8 = not available
9 = control probe
10 = virtual probe
11 to 14 = not available
15 = actual control set point
9 0 15 -
/tE /t2 Display on remote display - see /t1 0 0 15 -
A8 A3 Defrost terminated after maximum time signal:
0 = disabled; 1 = enabled
30 1 240 min
d8d Add High temperature alarm bypass time for door open 5 1 240 min
ALF AF Frost protection alarm threshold -5/ -9 -50/ -58 200/392 °C/°F
AdF Afd Frost protection alarm delay time 1 0 15 min
d9 c7 Defrost priority over continuous cycle:
0 = continuous cycle has priority; 1 = defrost has priority
0 0 1 -
cc, cPd cc Continuous cycle running time (0 = disabled) 0 0 72 h
c7 cPt Maximum pump down time (0 = pump down disabled) 0 0 900 s
d3 d15 Start defrost threshold 0 0 240 min
d12 d7 Skip defrost: 0 = disabled; 1 = enabled 0 0 1 -
A4, A5, A9 DIA Assign immediate external alarm digital input:
0 = Disabled; 1 = DI1; 2 = DI2; 3, 4 = Not available
... 0 4 -
DIb Assign delayed external alarm digital input - see DIA ... 0 4 -
DIc Assign start defrost digital input - see DIA ... 0 4 -
DId Assign start defrost digital input - see DIA ... 0 4 -
DIE Assign door switch with compressor OFF digital input - see DIA ... 0 4 -
DIF Assign remote ON/OFF digital input - see DIA ... 0 4 -
DIG Assign curtain switch digital input - see DIA ... 0 4 -
DIH Assign start/stop continuous cycle digital input - see DIA ... 0 4 -
DIP Assign door switch without compressor OFF digital input - see DIA ... 0 4 -
DIS Assign generic function alarm digital input logic see DIA ... 0 4 -
DIt Assign low pressure switch digital input see DIA ... 0 4 -
DIU Assign AUX output activation digital input see DIA ... 0 4 -
